Features
| FEATURES | BENEFITS |
| Surpassed rugged industry standards | All Land Pride cutters have been designed and tested and meet rigorous voluntary testing procedures specified by ANSI. |
| Gearbox Seal Protection | Gearbox bottom seal protection for longer bearing life. |
| 130 Horsepower gearbox | A rugged heavy built gearbox capable of handling heavy cutting applications. |
| Cat. 4 driveline with 4-plate slip-clutch | Excellent gearbox protection with the slip-clutch slipping when encountering obstruction in blade path. Standard slip-clutch offers convenience over shear-bolts. |
| Cat. II or III hitch with floating top link | Permits deck to follow the terrain for an even cut. |
| Quick Hitch Capability | Quick Hitch provides for fast hook-up. |
| Lower clevis type 3-Point hitch | Allows for ease of hook-up to tractor. Also adds additional strength allowing for an even pull from the tractor’s lower arms, vs. pulling on a single pin design. |
| 84" Cutting width | Wide cutting width, Reduces cutting time in the field. |
| Heavy 10 gauge deck & 1/4" side skirt construction | 10 gauge deck can withstand more abuse than lighter gauge decks and 1/4" side skirts provide excellent reinforcement and also protect sides from debris being thrown against them from the blades. |
| Box tubing deck supports | Makes for a stronger rigid deck. |
| Fully welded deck | Robotic welded. Adds additional strength and deck integrity. |
| Extended cutter front | For increased material flow and added protection. |
| Round back design | Helps discharge grass better than enclosed or partially enclosed cutters. |
| Deck Height 10 1/8" (RCF2784) 9 7/8" (RCR2684) |
Allows cutter to handle heavy cutting conditions. |
| 1 1/2" to 12" Cutting height | Provides for a wide range of cutting conditions. |
| High cutting capacity | Can cut brushy areas with saplings up to 3". |
| Full length skids with replaceable shoes | Full length skids protect side plate structure, replaceable shoes for convenience. |
| 1/2" x 4" Heat-treated free swinging blades | Free swinging protects from obstructions. Heat-treated offers longer life. |
| Splined blade bar | Allows for tight positive fit of stump jumper and blade bar to gearbox output shaft. |
| Oval stump jumper | Standard stump jumper aids in sliding over obstructions such as stumps, rocks and debris, which also helps protect gearbox output shaft. |
| High blade tip speed | Ensures clean cut. (14,369 fpm) |
| Available with single or dual tailwheel | Dual tailwheels offer greater stability in uneven terrain |
| 15" Laminated tailwheel | Laminated material is long lasting in rough conditions. Can't go flat. |
| 1 1/2" Heavy-duty spindle on tailwheel | Tailwheels take a beating, spindle gives the strength to protect tailwheel assembly. |
| Optional Front Guarding | Protect against flying debris. Customer can choose to include single chain, double chain or rubber guarding. |
| Optional rear guarding | Protect against flying debris. Customer can choose to include single chain or double chain. |
| Standard rear metal band | Protects against flying debris. Acts as a baffle o help mulch cuttings into smaller pieces. |
Specs
| Model | RCF2784 |
| Machine weight 3-Point single tailwheel 3-Point dual tailwheel Pull-type dual tailwheel |
1,354 lbs. with front & rear chain guards 1,427 lbs. with front & rear chain guards 1,632 lbs. with front & rear chain guards and hydraulic adjustment |
| 3-Point hitch | Category II & III with floating top linkage, quick hitch adaptable |
| Pull type tongue weight | 687 lbs. |
| Cutting width | 84" |
| Overall width | 89" |
| Overall length 3-Point single tailwheel 3-Point dual tailwheel Pull-type dual tailwheel |
132 1/2" 130 3/8" 159 1/4" |
| Deck height (bottom of deck to bottom of skid shoe) |
10 1/8" |
| Cutting height | 1 1/2" to 12" |
| Cutting capacity | 3" Diameter |
| Recommended tractor power take-off horsepower |
60-130 horsepower |
| Power take-off speed | 540 rpm |
| Gearbox ratio | 1:1.21 |
| Gearbox construction | Speed-up beveled gears, cast iron housing, 1 3/8"-6 spline input shaft and 2" output shaft |
| Gearbox oil capacity & type | 6.5 Pints of EP 80-90W gear lube |
| Deck construction | All welded deck |
| Deck material thickness | 10 Gauge |
| Side skirt material thickness | 1/4" |
| Skid shoes | 1/4" thick bolt-on replaceable skid shoes |
| Stump jumper | 3/16" x 24" x 38" Oval pan with 1" thick blade holder bar |
| Blades (2) | 1/2" x 4" x 31" Heat treated alloy steel free-swinging high lift |
| Blade bolts | Keyed with harden flat washers & lock nuts. |
| Blade tip speed | 14,369 FPM |
| Driveline | ASAE Category 4 |
| Driveline protection | 4 Plate slip clutch |
| Tailwheel mount | Welded A-arm and caster fork with 360 degree swivel |
| Tailwheel | 4" x 8" x 15" Laminated tire with cast iron hub |
| Front guard | Rubber guard (optional) Single chain guard (optional) Double chain guard (optional) |
| Rear guard | Metal band (standard) Single chain guard (optional Double chain guard (optional) |
