Features
| FEATURES | BENEFITS |
| Surpassed rugged industry standards | All Land Pride Cutters have been designed and tested and meet rigorous voluntary testing procedures specified by ANSI. |
| Gearbox Seal Protection | Gearbox bottom seal protection for longer bearing life. |
| Cat. 4 drive-line with 2-plate slip-clutch | Slip-clutch drive-line offers convenience for continual work. |
| Dual position clevis type 3-Point floating top link | Permits deck to follow the terrain for an even cut. |
| Lower clevis type 3-Point hitch | Allows for ease of hook-up to tractor. Also adds additional strength allowing for an even pull from the tractor's lower arms, vs. pulling on a single pin design. |
| Heavy 10 gauge deck & side skirt construction | Can withstand more abuse than lighter gauge decks. |
| Box tubing deck supports | Makes for a stronger rigid deck. |
| Fully welded deck | Adds additional strength. |
| Extended cutter front | For increased material flow and added protection. |
| Round back design | Helps discharge grass better than enclosed or partially enclosed cutters. |
| 11 15/16" Deck Height | Allows cutter to handle heavy cutting conditions. |
| 1 1/2" to 12" Cutting height | Provides for a wide range of cutting conditions. |
| Full length skid shoes | Provides sidewall reinforcement and full protection to bottom of sidewall. |
| 1/2" x 4" Heat-treated free swinging blades | Free swinging protects from obstructions. Heat-treated offers longer life. |
| Splined blade bar hub | Allows for tight positive fit of stump jumper and blade bar to gearbox output shaft. |
| 3/16" x 27" Oval stump jumper | Standard Oval stump jumper slides over stumps, rocks and debris. |
| High blade tip speed | Ensures clean cut. |
| 15" Laminated tail-wheel | Laminated material is long lasting in rough conditions. Can't go flat. |
| 1 1/4" Heavy-duty spindle on tail-wheel | Tail-wheels take a beating, spindle gives the strength to protect tail-wheel assembly. |
| Optional Front Guarding | Protect against flying debris. Customer can choose to include single chain or rubber guarding. |
| Optional Rear Guarding | Protect against flying debris. Rear Metal Band is standard. Customer can choose to include single chain guarding. |
| Drive-line Holder | Keeps drive-line up out of dirt. Easier hook up of drive-line. |
Specs
| Specifications & Capacities | |
| Machine Weight: Single Tail-wheel Dual Tail-wheel |
1,047 lbs. with Front Rubber Guard and Rear Metal Band. 1,155 lbs. with Front Rubber Guard and Rear Metal Band. |
| Hitch | Category l & II with floating top linkage, Quick Hitch ready |
| Cutting Width | 84" |
| Overall Width | 89" |
| Overall Length: Single Tail-wheel Dual Tail-wheel |
133 1/4" 126" |
| Deck Height (Bottom of Deck to Bottom of Skid Shoe) | 11 15/16" |
| Cutting Height | 1 1/2" to 12" |
| Cutting Capacity | 2" Diameter |
| Recommended tractor hp | 45-90 hp |
| Power take-off speed | 540 rpm |
| Gearbox Ratio | 1:1.44 |
| Gearbox Construction | Speed-up beveled gears, cast iron housing, 1 3/8"-6 spline input shaft and 2" output shaft |
| Gearbox Oil Capacity & Type | 7 Pints of EP 80-90W oil |
| Deck Construction | All welded deck |
| Deck Material Thickness | 10 Gauge (.134") |
| Side Skirt Material Thickness | 10 Gauge (.134") |
| Skid Shoes: Standard Accessory |
Full length weld-on skid shoes 1/4" x 2 1/2" x 18 7/16" Long bolt-on replaceable skid shoes (Bolts to weld-on skid shoes) |
| Stump Jumper | 3/16" x 27" Oval Pan with 1" thick blade holder bar |
| Blades (2) | 1/2" x 4" x 31" Heat treated alloy steel free-swinging high lift |
| Blade Bolts | Keyed with harden flat washers & lock nuts. |
| Blade Tip Speed | 17,113 FPM |
| Drive-line | ASAE Category 4 |
| Drive-line Protection | 2 Plate slip clutch |
| Tail-wheel Mount | Welded A-arm and caster fork with 360 degree swivel |
| Tail-wheel | 4" x 8" x 15" Laminated tire with cast iron hub |
| Front Guard: Optional Optional |
Rubber Belting Single Chain Guard |
| Rear Guard: Standard Optional |
Metal Band Single Chain Guard |
