Features
| Universal Quick Attach Hitch | Fits a wide variety of skid steer loaders and compact track loaders rated up to 100 hp. Makes the Concrete Claw quick and easy to attach. |
| High strength T1 steel side panels | Resists bending forces while prying-up concrete slabs. |
| Side panels are reinforced with continuous welded bottom plate, top plate, and top rectangle tube |
Adds strength and rigidity to the attachment. |
| 3/4" x 6" Continuous welded front cutting edge | Adds strength to the attachment and stands up to high wear. |
| Replaceable pin-on tooth tips | Can be easily replaced as they wear or break. |
| Two, bolt-on cast steel skid steps | Makes entering and exiting the power machine safer. |
Specs
| Maximum horsepower hp (kW) | 100 (76.6) |
| Weight lbs (kg) | 590 (268) |
| Hitch type | Universal Quick Attach Hitch |
| Overall working width in (cm) | 25 1/2 (65) Distance from outside of side plate to outside of side plate. |
| Working depth in (cm) | 48 3/4 (124 cm) |
| Rear opening in (cm) | 7 3/4 (20) |
| Number of replaceable pin-on teeth | 3 |
| Pin-on tooth construction in (mm) | Cast iron tooth attaches to a welded on cast steel base with a tooth locking pin. |
| Side plate construction in (mm) | Continuous welded 3/4 (19) T1 steel |
| Bottom plate construction in (mm) | Continuous welded 1/2 (13) steel |
| Front cutting edge construction | Continuous welded 3/4" x 8" (19 mm x 20 cm) high carbon heat treated steel |
