Features
Adjustable Speed Control
This allows speed control which aids in the training of new operators
Wings Pivot 15 Degrees
The wings pivot up and down 15 degrees to reduce the possibility of scalping.
1/4" Steel Impact Plate
Protects the deck from everyday wear and tear, increasing the life of the deck.
76" Transport Width
76" width fits most trailers for easy travel between jobs.
54" Center Deck & 88" Width of Cut
Cut quality of a 54" deck plus the productivity of an 88" deck.
Powerful Engine Options
Choose from Vanguard BigBlock™ or Vanguard BigBlock™ EFI Oil Guard engines.
Specs
| Key Specs | Super 88 |
| ENGINE MANUFACTURER | Vanguard BigBlock, Vanguard BigBlock EFI w/ Oil Guard |
| ENGINE HORSEPOWER | 36, 37 |
| TRANSMISSION | Hydro-Gear 21cc pump with Parker TG wheel motors |
| FUEL CAPACITY | 13.9 gal. |
| GROUND SPEED (FWD) | Up to 10 mph |
| CUTTING WIDTH | 88" |
| CUTTING HEIGHT | 2" to 5.5" |
| FRONT TIRE | 13 x 6.5-6 |
| DRIVE TIRE | 26 x 12-12 |
| Engine | |
| ENGINE MANUFACTURER | Vanguard BigBlock, Vanguard BigBlock EFI w/ Oil Guard |
| ENGINE HORSEPOWER | 36, 37 |
| DISPLACEMENT | 993cc |
| COOLING | Air Cooled |
| AIR CLEANER | Heavy duty air canister |
| Drive System | |
| TYPE | Dual Hydrostatic |
| TRANSMISSION | Hydro-Gear 21cc pump with Parker TG wheel motors |
| HYDRAULIC LINES | |
| RESERVOIR CAPACITY | |
| HYDRAULIC COOLING | |
| FUEL CAPACITY | 13.9 gal. |
| GROUND SPEED (FWD) | Up to 10 mph |
| PARKING BRAKE | Hand operated/ drum brakes |
| Deck | |
| CUTTING WIDTH | 88" |
| CUTTING HEIGHT | 2" to 5.5" |
| DECK DEPTH | 5.5" |
| DECK LIFT | Center Deck: Electric Actuator Wings: Manual with pull-out lift assist handles |
| NUMBER OF BLADES | 5 |
| BLADE LENGTH | 18.5" |
| BLADE TIP SPEED | 16,800 |
| SPINDLES | Ductile cast iron w/ steel shaft & sealed ball bearings |
| DECK ENGAGEMENT | Warner Electric PTO Clutch |
| DECK MATERIAL | Fabricated 11ga welded steel |
| SPINDLE MOUNTS | 7 gauge doubler |
| IMPACT TRIM AREA | .25" thick plate |
| ANTI-SCALP WHEELS | Cast iron wing anti-scalp wheels with bearings with agriculture seals |
| Construction | |
| FRAME | 1.5" x 3" wall |
| ENGINE PLATE | 7ga |
| OPERATOR PLATFORM | 7ga |
| FRONT AXLE | Fabricated with tapered roller bearings |
| FRONT CASTER WHEEL | Tapered wheel bearings and debris cap |
| FRONT CASTER FORK | Fabricated 1/2" steel |
| General | |
| SEAT | Bolstered operator pad |
| CUP HOLDER | N/A |
| Dimensions | |
| FRONT TIRE (INCHES) | 13 x 6.5-6 |
| DRIVE TIRE (INCHES) | 26 x 12-12 |
| WING TIRE (INCHES) | 11 x 4 Semi-Pneumatic |
| WEIGHT (LBS) | 2057 |
| HEIGHT (INCHES) | 50 |
| LENGTH (INCHES) | 84 |
| WIDTH W/ CHUTE UP (INCHES) | 91.1" with wings down, 76" with wings up and gauge wheel set at 3.25" cut height |
| TIRE-TO-TIRE WIDTH (INCHES) | 57 |
| PRODUCTIVITY (ACRES PER HOUR) | 7.11 |
Accessories and Attachments
Light Kit
Extend your productivity into the late hours with our optional light kit.
Fits:
Super S
Super 88
Super SF
Surfer Pro
Mud Flap Kit
Mud flaps for rear drive tires.
Fits:
Super SF
Super 88
