Attachment Capable
Easily breaks down for safer transport and compact storage
Smart Start® Technology
Specially-designed engine and starter for easy and fast starting with minimum effort
Quick Start with Air Purge
Air purge removes air from carburetor and fuel system for easy starting
Ergonomic Design
Comfortable curved handle for easier use and less fatigue
High Line Capacity
Tap 'n' Go trimmer head is easy to use and refill
Simple Starting
Stop switch automatically resets to ON so trimmer is ready for next use
Intuitive controls
Easy to use and maneuver
Cutting System | 122LK SKU: 967 62 82‑01 |
Cutting width | 17 in |
Engine | |
Cylinder displacement | 1.32 cu.inch |
Cylinder displacement | 21.7 cm³ |
Power output | 0.8 hp |
Maximum power speed | 7,800 rpm |
Fuel tank volume | 10.14 fl oz |
Fuel consumption | 630 g/kWh |
Fuel consumption | 0.79 lbs/h |
Idling speed | 2,800 rpm |
Spark plug | Husqvarna HQT-4 672201 |
Electrode gap | 0.02 in |
Torque, max. at rpm | 6,000 rpm |
Torque, max. | 0.8 Nm |
Clutch engagement speed (±120) | 4,200 rpm |
Maximum rpm output shaft | 6,850 rpm |
Dimensions | |
Weight (excl. cutting equipment) | 10.58 lbs |
Product size length | 70.1 in |
Product size width | 9.5 in |
Tube length | 58.268 in |
Product size height | 9.8 in |
Tube diameter | 1 in |
Equipment | |
Grass blade | Not included |
Harness | Single harness |
Trimmer head | T25 (L) |
Saw blade | Not included |
Transmission | |
Gear ratio | 1.46 |
Drive gear angle | 30 ° |
Emission | |
Exhaust emissions (CO average) | 254.87 g/kWh |
Exhaust emissions (CO average) | 254.87 g/kWh |
Exhaust emissions (CO average) | 230.89 g/kWh |
Vibration | |
Equivalent vibration level (ahv, eq) left handle | 3.6 m/s² |
Equivalent vibration level (ahv, eq) right handle | 3.5 m/s² |
Equivalent vibration level (ahv, eq) front handle | 3.6 m/s² |
Equivalent vibration level (ahv, eq) rear handle | 3.5 m/s² |
Certifications | |
WEEE Classified | No |
Sound and Noise | |
Sound pressure level at operators ear | 90 dB(A) |
Sound power level, guaranteed (LWA) | 108 dB(A) |
Lubricant | |
Lubricant type (Engine) | Husqvarna 2 stroke or equiv. at 50:1 |
