The Model 127V mid-mount delivers the same professional-quality features of zero-radius maneuverability, comfort, performance and durability of larger Grasshopper models. This small-frame riding lawn mower offers a compact wheelbase that provides easy transport on trailers and fits easily into shops or garages with limited space. Ideal for residential owners or landscapers.
  • Get a Quote Value Your Trade Request Brochure
  • Send to a Friend
  • Payment Calculator

    • Get information on the Model 127V

    Fields with asterisks* are required. Please email our helpful staff with any questions or comments using the contact form.

    Request Brochure

    Fields with asterisks* are required. Please email our helpful staff with any questions or comments using the contact form.

    Send your friend information on the Model 127V

    Fields with asterisks* are required. Your friend will receive an email that contains a reference to this page. Please send this email only to people you know who would be interested in this information.

    Requesting Trade In on Model 127V

    Contact Information
    Equipment Interested In
    Trade Information

    Request A Demo

    Fields with asterisks* are required.

    Loan Calculator

    Use the Loan Calculator to help you determine the financing and payment options that are best for you.

    Amount Financed ($)
    Interest Rate (%)
    Loan Term in Months
    Monthly Payment Calculated

    **The accuracy of this calculator and its applicability to your circumstances is not guaranteed. You should obtain personal advice from qualified professionals. This information is provided for illustrative purposes only and does not constitute an application. This notice does not guarantee loan approval, nor is it an offer or commitment to make a loan to you on the above terms.

Shopping Tools
Contact Salesman
Request Demo
Apply for Financing

Model 127V Features & Benefits

Heavy-duty Deck

  • Extra-deep, 5.5-inch deck is fabricated from heavy-gauge formed steel with a reinforced anvil edge
  • Specially designed cutting chambers enhance airflow for better cut quality
  • Deck easily converts from side discharge to optional Down Discharge™ mulching or PowerVac™ collection
  • Sentry™ spindles with massive, 8-inch flanges anchored in a 6-bolt pattern, spread the force of impact for greater strength
  • Spindle planes are fabricated from double-layered formed steel laminate and combine with the spindles to form a triple-strength deck to keep blades level and deliver a high-quality cut.
  • Sentry™ spindle guards shield spindle housing and seal lower bearings from fiber wrap and dirt ingestion



Vigilant Operator Presence System™

  • Standard, low profile operator protection structure (OPS) with an adjustable seatbelt
  • Dampened steering levers that return to neutral from forward and reverse
  • Interlock switches that shut down the engine when the operator leaves the seat while PTO is engaged or levers are in drive position



B&S Commercial Turf Engine

  • Powerful 810 cc Commercial Turf OHV V-Twin engine
  • Heavy-duty components enhance power and reliability
  • Five-step, Integrated Cyclonic Air Management System for cleaner performance
  • Extended maintenance intervals
  • Three-year limited commercial engine manufacturer warranty (see dealer for details)



Shock Impact Reduction System™(SIRS™)

  • Unrivaled comfort with iso-mounted Ultimate Suspension Ride™ scuff-resistant, Cordura®-covered, deep-cushioned, high-back seat with padded lumbar support and armrests
  • Roomy, iso-mounted, shock-absorbing footrest



QuikAjust® Drop Pin Height Adjustment

  • Raise and lower the deck easily with foot pedal and drop pin for precision cutting heights between 1.0 and 5.0 inches.



Reduced Maintenance

  • Only two Access-Eze™ lubrication points cut maintenance time up to 95%
  • Self-tensioning belts minimize cost and labor on routine maintenance



Rugged Construction

  • Robotically-welded steel construction for long-lasting durability
  • Centered-bearing design provides greater load-bearing capacity to handle the weight of operator, fuel and high-capacity collector with reserve strength for curb shocks and weight shifts
  • Tough-as-nails powder-coated finish is fusion-bonded for chip and rust resistance



Ultimate Operator Station™

  • The deep-cushioned, deluxe Premium Comfort Seat features a coil-spring suspension and padded lumbar support with sliding 2-inch fore and aft adjustment for all-day comfort. Iso-mounting eliminates vibration before it reaches the seat, and both padded seat and foldable armrests are covered in scuff-resistant, breathable CoolTemp Cordura® fabric, which dissipates heat and won’t tear or crack with extended use.
  • Operational controls including throttle, ignition and push/pull PTO switches, choke, angled View-Eze™ console and adjustable cup holder are well positioned for visibility and ease of reach.
  • One- or two-handed operation with ComfortReach™ adjustable Hydra-Smooth™ dual levers that automatically return to neutral from either forward or reverse position.

Model 127V Specs & Compare

ENGINE
Type/Horsepower/Cylinders B&S Commercial Turf, V-Twin
Displacement 49.4 cu. in. (810 cc)
Lubrication System Pressure Lube/Filter
Crankshaft Vertical
Cooling System Air
Fuel Gasoline - unleaded
Fuel Capacity 6.5 U.S. Gal. (24.6 l)
Optional Fuel Capacity NA
Air Cleaner Integrated, cyclonic air cleaner with 5-step debris management system
Muffler Ultra quiet, single, industrial type.
DURAMAX® DECKS
DECK NA
Mulching Package # 504567(52), 504569(61)
DURAMAX® DECK SIZE – 41" Deck NA
– 42" Deck NA
– 44" Deck NA
– 48" Deck NA
– 52" Deck *
– 61" Deck *
– 72" Deck NA
CUTTING HEIGHT RANGE 1.0 to 4.5 in. (2.5 to 11.4 cm)
CONSTRUCTION (Robotic-welded steel) Double-layered 10-gauge plus 10-gauge formed-steel spindle plane 0.269 in (6.83 mm) thick with 7-gauge skirts. Anvil-edge design (48) with 0.5 in. (12.7 mm) reinforcement on front edge of deck.
BLADES (Tempered, alloy steel) – 41" Deck NA
– 42" Deck NA
– 44" Deck NA
– 48" Deck NA
– 52" Deck (3) 18 in. (45.7 cm)
– 61" Deck (3) 21 in. (53.3 cm)
– 72" Deck NA
SPINDLE ASSEMBLIES Sentry™ Spindle System, 2.5 cm (approx. 1 in.) O.D. shaft. Spindle head designed to eliminate fiber wrap. Double bearings, non-greasable. Spindle cones shield housing and lower bearings from fiber wrap and dirt ingestion.
SPINDLE HOUSINGS 8 in. (20.3 cm)-diameter machined aluminum housing with 6-bolt pattern.
BLADE DRIVE Belt drive with single Kevlar V-belt and idler arm tensioning.
TRIMABILITY (Outside of std. tire to left trim side) – 41" Deck NA
– 42" Deck NA
– 44" Deck NA
– 48" Deck NA
– 52" Deck NA
– 61" Deck NA
– 72" Deck NA
STARTER & ELECTRICAL SYSTEM
Battery (maintenance-free) 12 Volt
Starter Solenoid shift
Ignition Breakerless
Interlock System Prevents engine start when PTO clutch is engaged or steering levers are in drive position. Allows operator dismount without engine shutdown only when PTO is disengaged and steering levers are locked in neutral.
ULTIMATE OPERATOR STATION
Seat Iso-mounted Premium Comfort Seat. Features include a high-back, deep-cushioned, foam-padded Cordura®-covered, padded foldable arm rests, padded backrest with lumbar support, coil-spring suspension and embroidered Grasshopper logo on seat back. Adjustable fore and aft.
Suspension Roomy, iso-mounted footrest with Shock Impact Reduction System™ (SIRS™).
Console-mounted Instruments Digital hour meter, parking brake indicator light, ignition switch, choke and push/pull PTO switch.
Work Lights Optional - LED
Hour Meter Standard
TRANSMISSION & STEERING
Type Design-matched hydrostatic system with in-line cooling fans. Fully hydraulic, integrated Parker HT Series transmission with variable displacement piston-type pumps and high-torque wheel motors for each drive wheel.
Filtration/Hydro Fluid Internal field-serviceable filter / No break-in oil change required; best-in-class service intervals with CoolTemp Hydro-Max™ fluid.
Speed 0 - 8.0 mph (0 - 12.9 kph) forward 0 - 6.0 mph (0 - 9.7 kph) reverse
Turning Radius True zero degree, turns within own length with counter-rotating, independently powered drive wheels.
Steering One- or two-hand operation with adjustable HydraSmooth™ dual levers that automatically return to neutral from either forward or reverse position.
Brakes Dynamic braking through hydrostatic transmission.
Parking Brake Compression
Attachment Drive NA
MidMount
Drive Wheels - Standard (4-ply rated) – 41" Deck NA
– 42" Deck NA
– 44" Deck NA
– 48" Deck NA
– 52" Deck 20x10x10 turf, 4-ply rated
– 61" Deck 20x12.00x10
– 72" Deck NA
Drive Wheels - Optional (4-ply rated) NA
Front Wheels - All Models 13x6.50x6; pneumatic with greasable, double-sealed bearings to protect from grass wrap.
FrontMount
Drive Wheels - Standard (4-ply rated) NA
Drive Wheels - Optional (4-ply rated) NA
Single Tail Wheel NA
Wide Stance Single Fork Tail Wheel NA
Deck Tires (4-ply rated) – 41" Deck NA
– 42" Deck
– 44" Deck NA
– 48" Deck NA
– 52" Deck NA
– 61" Deck NA
– 72" Deck NA
DIMENSIONS
Height (Seat Back) 47.0 in. (119.4 cm)
Height (Seat Cushion) 29.0 in. (73.7 cm)
Height (ROPS) 59.0 in. (149.9 cm)
Length (midmount w/ DuraMax® Deck - Mowing Position) – 41" Deck NA
– 42" Deck NA
– 44" Deck NA
– 48" Deck NA
– 52" Deck 75.0 in. (190.5 cm)
– 61" Deck 78.0 in. (198.1 cm
– 72" Deck NA
Length (FrontMount Power Unit + DuraMax® Deck - Folded Up) – 41" Deck NA
– 42" Deck NA
– 44" Deck NA
– 48" Deck NA
– 52" Deck NA
– 61" Deck NA
– 72" Deck NA
Deck Width (Side Discharge) – 41" Deck NA
– 42" Deck NA
– 44" Deck NA
– 48" Deck NA
– 52" Deck 65.5 in. (166.5 cm)
– 61" Deck 74.5 in. (189.2 cm)
– 72" Deck NA
Deck Width (Mulch*) – 41" Deck NA
– 42" Deck NA
– 44" Deck NA
– 48" Deck NA
– 52" Deck 53.5 in.* (135.9 cm)
– 61" Deck 62.5 in.* (158.8 cm)
– 72" Deck NA
FrontMount PowerUnit Only (Width/Length) NA
FrontMount Power Unit (Wheelbase) NA
WEIGHT
(Uncrated) – 41" Deck NA
– 42" Deck NA
– 44" Deck NA
– 48" Deck NA
– 52" Deck 830 lbs.(376.5 kg)
– 61" Deck 880 lbs.(399.2 kg)
– 72" Deck NA
FrontMount Power Unit Only (uncrated) NA
FrontMount Deck Only - Side Discharge (uncrated) – 41" Deck NA
– 42" Deck NA
– 44" Deck NA
– 48" Deck NA
– 52" Deck NA
– 61" Deck NA
– 72" Deck NA
Mulching Package – 41" Deck NA
– 42" Deck NA
– 44" Deck NA
– 48" Deck NA
– 52" Deck 29 lbs. (13.2 kg)
– 61" Deck 36 lbs. (16.3 kg)
– 72" Deck NA
All specifications and information displayed on this Web site are subject to change without notice.
