Features
12 Feet of Spray Coverage
Six spray nozzles supplied by direct controllable independent hoses provide consistent spray tip volume and eliminates spikes and unequal tip pressure during operation.
Industry-Leading Capacity
The Voyager offers 80 gallons of liquid capacity, 250 pounds of granular capacity and molded side pockets to carry an additional 100 pounds of granular material for an additional 200,000 sq.ft. of coverage per day over other units.
Pivoting Front Axle
Ensures that all four wheels hold their contact with terrain for a smoother ride while maintaining more consistent ground to nozzle distance in uneven terrain.
Iso-Mounted Operator Platform
Cushions rough terrain for enhanced operator comfort and is positioned directly over the drive wheels. This improves the vehicle's center of gravity and reduces operator acceleration during turning for a more comfortable driving experience.
Three-Section Breakaway Boom
Two outward folding boom sections can be released from the operator platform and feature bi-directional breakaway to prevent boom damage.
100% Stainless Steel Frame
Resists rust and corrosion from chemicals.
Specs
| Engine Model | Vanguard® V-Twin |
| Power Rating (gross hp) | 23 |
| Fuel Capacity - gal (L) | 9 (34.1) |
| Speed (mph) | 8 |
| Front Tires | 16 x 8.5 - 8 |
| Rear Tires | 24 x 12 - 12 |
| Spreader Hopper Capacity (lbs.) | 250 |
| Granular Coverage per Fill - sq.ft. (acres) | 62,500 (1.43) |
| Variable Spread Width | 3' to 25' |
| Spray Pump | 9.2 gpm roller pump |
| Sprayer Tank Capacity - gal (L) | 80 (302.8) |
| Spray Width | 4', 8' or 12' |
| Liquid Coverage per Fill - sq.ft. (acres) | 320,000 (7.35) |
| Overall Length - in. (cm) | 79 (200.6) |
| Overall Width - in. (cm) | 61 (154.9) |
| Overall Height - in. (cm) | 50 (127) |
| Dry Weight - lbs. (kg) | 1,406 (637.7) |
| Full Weight - lbs. (kg) | 2,600 (1,179.3) |
