• 16” Diameter
  • 85’ – 125’ Lengths
  • Up to 23,000 bph
  • A-frame
  • Get a Quote Value Your Trade Request Brochure
  • Send to a Friend
  • Payment Calculator

    • Get information on the MKX2 16-125

    Fields with asterisks* are required. Please email our helpful staff with any questions or comments using the contact form.

    Request Brochure

    Fields with asterisks* are required. Please email our helpful staff with any questions or comments using the contact form.

    Send your friend information on the MKX2 16-125

    Fields with asterisks* are required. Your friend will receive an email that contains a reference to this page. Please send this email only to people you know who would be interested in this information.

    Requesting Trade In on MKX2 16-125

    Contact Information
    Equipment Interested In
    Trade Information

    Request A Demo

    Fields with asterisks* are required.

    Loan Calculator

    Use the Loan Calculator to help you determine the financing and payment options that are best for you.

    Amount Financed ($)
    Interest Rate (%)
    Loan Term in Months
    Monthly Payment Calculated

    **The accuracy of this calculator and its applicability to your circumstances is not guaranteed. You should obtain personal advice from qualified professionals. This information is provided for illustrative purposes only and does not constitute an application. This notice does not guarantee loan approval, nor is it an offer or commitment to make a loan to you on the above terms.

Shopping Tools
Contact Salesman
Request Demo
Apply for Financing

MKX2 16-125 Features & Benefits

KEY FEATURES

  • New open discharge spout
  • Rigid steel trussing
  • Stable A-frame support
  • Standard steerable axles



OPTIONS

  • X-Tend hopper
  • Poly flex spout

MKX2 16-125 Specs & Compare

MODELMKX2 16-125
TUBE GAUGE10 ga
TUBE CONNECTORS1/4" (0.6 cm) angle flange
MAIN FLIGHTING15" (38.1 cm) x 1/4" (0.6 cm) stretched & welded
WEAR EDGE TECHNOLOGY TM
(REINFORCED FLIGHT)		1/4" (0.6 cm) main flighting with Wear Edge TechnologyTM on critical grain transfer points
AR BOOT FLIGHT1/4" (0.6 cm)
FLIGHTING SHAFT3.5" (8.9 cm) x 11 ga tubing; square flight connector
GREASELESS HANGER BEARING FOR BOOT (NEW)2 3/8" (6 cm) ID, triple seal
UPPER BEARING2" (5.1 cm) taper roller bearing assembly
SPEED REDUCER GEARBOXEnclosed, cast casing, 1000 rpm reducing gearbox (540 rpm) with reversing capability
TUBE TRUSSING3.5" (8.9 cm) x 11 ga tubing; 1/2" (1.3 cm) cable stays
HYDRAULIC LIFT2" (5.1cm) x 6 1/2" (16.5 cm) bore cylinders; 1/2" (1.3 cm) aircraft cable
UNDERCARRIAGE4" (10.2cm) x 8" (20.3cm) HSS tubing
AXLE4" (10.2 cm) x 4" (10.2 cm) x 3/16" (0.5cm) tubing; 4" (10.2 cm) x 4" (10.2 cm) x 1/4" (0.6 cm) on extensions
HUB8-bolt agricultural type
TIRES22.5" (57.2 cm) agricultural tires
PTO SHAFT50E double CV with 2-bolt shear
PARKING JACK12,000 lbs (5443.1 kg)
LOW PROFILE HOPPER DIMENSIONS68" (172.7 cm) length x 46 ½" (121.9 cm) width x 11" (27.9 cm) height with flat free tires
PSI REQUIRED TO RAISE AUGER2000 psi (137.9 bar)
HP REQUIRED (WITH DRY WHEAT)195 - 225 hp
WHEEL TREAD148" - 182" (375.9 - 462.3 cm)
TRANSPORT HEIGHT (18" HITCH)17' 6" (5.3 m)
