• 10” Diameter
  • 53’ – 83’ Lengths
  • Up to 6,000 bph
  • Available in both Scissor lift and a-frame
  • Get a Quote Value Your Trade Request Brochure
  • Send to a Friend
  • Payment Calculator

    • Get information on the MKX2 10-63

    Fields with asterisks* are required. Please email our helpful staff with any questions or comments using the contact form.

    Request Brochure

    Fields with asterisks* are required. Please email our helpful staff with any questions or comments using the contact form.

    Send your friend information on the MKX2 10-63

    Fields with asterisks* are required. Your friend will receive an email that contains a reference to this page. Please send this email only to people you know who would be interested in this information.

    Requesting Trade In on MKX2 10-63

    Contact Information
    Equipment Interested In
    Trade Information

    Request A Demo

    Fields with asterisks* are required.

    Loan Calculator

    Use the Loan Calculator to help you determine the financing and payment options that are best for you.

    Amount Financed ($)
    Interest Rate (%)
    Loan Term in Months
    Monthly Payment Calculated

    **The accuracy of this calculator and its applicability to your circumstances is not guaranteed. You should obtain personal advice from qualified professionals. This information is provided for illustrative purposes only and does not constitute an application. This notice does not guarantee loan approval, nor is it an offer or commitment to make a loan to you on the above terms.

Shopping Tools
Contact Salesman
Request Demo
Apply for Financing

MKX2 10-63 Features & Benefits

KEY FEATURES

  • New open discharge spout decreases horsepower requirements
  • Aircraft cable trussing
  • Stable A-frame support (53'-83')
  • Wide standing axles



OPTIONS

  • Hydraulic hopper winch
  • Electric and hydraulic power swing
  • Reverser kit
  • Corn screen
  • Poly flex spout
  • Right angle drive
  • LED work lights

MKX2 10-63 Specs & Compare

MODELMKX2 10-63
TUBE GAUGE12 ga
TUBE CONNECTORSHeavy-duty 3/16" (0.5 cm) angle flange
MAIN FLIGHTING9" (22.9 cm) OD x 7 ga stretched and welded with Wear Edge TechnologyTM on critical points
WEAR EDGE TECHNOLOGYTM (REINFORCED FLIGHT)1/4" (0.6 cm) plus 10 ga ribbon weld = 5/16" (0.8 cm) Wear Edge TechnologyTM on critical grain transfer points
FLIGHTING SHAFTHigh strength 2" (5.1 cm) OD x 11 ga tubing square flight connection
UPPER BEARING2" (5.1 cm) taper roller bearing assembly
LOWER BEARING1 1/2" (3.8 cm) pillow block greaseable ball bearing
TUBE TRUSSING5/16" (0.8 cm) aircraft type galvanized steel cable
HYDRAULIC LIFTSingle 4" (10.2 cm) cylinder with 5/16" (0.8 cm) aircraft cable
UNDERCARRIAGE3" (7.6 cm) x 11 ga A-frame
AXLE2 1/2" (6.4 cm) x 2 1/2" (6.4 cm) x 1/8" (0.3 cm) wall square tubing
HUB4-bolt agricultural type
TIRES15" (38.1 cm)
PTO SHAFT14E constant velocity with 5/16" (8 mm) shear bolt
PARKING JACK2000 lbs (907.2 kg) side wind
SPROCKET & CHAINHardened tooth sprocket with #60 chain
LOW PROFILE HOPPER DIMENSIONS60" (152.4 cm) length x 40" (101.6 cm) width x 10" (25.4 cm) height with flat free tires
PSI REQUIRED TO RAISE AUGER1200 psi (82.7 bar)
HP REQUIRED (WITH DRY WHEAT)50-60 hp
WHEEL TREAD112" (2.8 m)
TRANSPORT HEIGHT (18" HITCH)13' 6" (4.1 m)
