Features
Reverse gearbox
Improves maneuverability and control.
Counterweight
For safe and sturdy operation. The counterweight increases weight on the wheels and improves balance.
Reverse gear
Equipped with reverse gear to make work easier.
Power Forward and Reverse
One gear forward and one reverse, for easy operation, maneuverability and transport.
Specifications
Capacity
Working depth 6.5 in
Working width 17 in
Cultivator type Rear-tine
Depth adjustment steps 7
Dimensions
Weight 214 lbs
Transmission
Transmission type Chain/Gear
Transmission steps forward 1
Transmission steps reverse 1
Equipment
Reverse gearbox Yes
Vertically adjustable handlebar Yes
Handlebar-mounted gear selection Yes
Drag bar Yes
Engine
Cylinder displacement 9.76 cu.inch
Rotational speed 3600 rpm
Engine manufacturer Honda
Engine type GCV160
