Features
Free-wheel design
The unique patented free-wheeling outer tines allow users to continue aerating without losing speed on tight corners and without damaging turf.
Rear-wheel control
Rear-whee control, allowing adjustment of working depth and settings for maximum stability.
Detachable weights
Additional side weights allow for improved ground penetration and are removable for reduced effort when lifting or for altering weight balance on slopes and inclines.
Specifications
Equipment
Frame Construction Welded Steel
Powder coat paint Yes
Engine
Engine manufacturer Honda
Engine name GX120
Engine type HX2
Power 3 kW
Power 3.5 hp
Cylinder displacement 119.6 cm³
Air Filter type Dual
Oil capacity 37.2 fl oz
Fuel tank volume (with reserve) 0.66 gal (US)
Capacity
Aerating width 25 in
Aerating pattern 3.6 in
Aerating pattern 6.8 in
Number of tines 42
Detachable weights Two 36 lb weights
Aerating depth max 3 in
Aerating depth min 0 in
Drive system
Drive System V-belt, permalube chain
Dimensions
Weight (less fuel/water containers) 422 lbs
Product size, folded handle Height 28 inch
Product size, folded handle Length 33 in
Product size, folded handle Width 38 in
