Features
High blowing capacity
The powerful and easy to start engine in combination with efficient fan design delivers high air speed and air flow.
Ergonomic harness
Comfortable, ventilated and load-reducing harness with hip belt and wide shoulder straps.
Air Injection
Centrifugal air cleaning system removes larger dust and debris particles before reaching the air filter. This results in reduced air filter cleanings and improved engine life.
LowVib®
Dampeners between the engine and chassis effectively reduce vibrations.
Specifications
Capacity
Air flow in housing
766.33 cfm
Air flow in pipe
473.22 cfm
Air speed
177 mph
Air filter type
Foam
Engine
Cylinder displacement
51.7 cm³
Power output
3.2 hp
Maximum power speed
6000 rpm
Fuel tank volume
50.72 fl oz
Idling speed
2300 rpm
Electrode gap
0.02 in
Spark plug
NGK BPMR7A
Fuel consumption
400 g/kWh
Engine Family CARB
DHVXS.0525AC
Engine Family EPA
DHVXS.0525AC
Equipment
OEM Harness
Single harness
OEM Nozzle type
Round
Sound and Noise
Sound power level, guaranteed (LWA)
100 dB(A)
Sound power level, measured
99 dB(A)
Sound pressure level at operators ear
91 dB(A)
Vibration
Equivalent vibration level (ahv, eq) handle
3.9 m/s²
