Features
X-Torq® engine
The X-Torq® engine design reduces harmful exhaust emissions by up to 60% and increases fuel efficiency by up to 20%.
Adjustable handle bar
Adjustable and ergonomically designed handlebar for best comfort.
Adjustable harness hook eyelet
Adjustable eye let for best balance
Trio-Balance harness
Ergonomic harness with broad back support, shoulder straps and hip belt that distributes the load over a larger area.
Specifications
Dimensions
Weight (excl. cutting equipment) 18.3 lbs
Lubricant
Lubricant type (bevel gear) Biodegradable grease
Engine
Cylinder displacement 45.7 cm³
Power output 2.8 hp
Fuel tank volume 30.43 fl oz
Fuel consumption 450 g/kWh
Idling speed 2700 rpm
Ignition module air gap 0.01 in
Electrode gap 0.02 in
Clutch engagement speed (±120) 3900 rpm
Maximum rpm output shaft 8800 rpm
Sound and Noise
Sound power level, guaranteed (LWA) 117 dB(A)
Sound pressure level at operators ear 100 dB(A)
Transmission
Gear ratio 1.4
Vibration
Equivalent vibration level (ahv, eq) left handle 3.6 m/s²
Equivalent vibration level (ahv, eq) right handle 3.8 m/s²
Equipment
OEM Harness Balance X
OEM Saw blade Scarlett 200-22
