Features
AutoTune
AutoTune gives optimal engine performance throughout automatic engine setting.
No time spent on carburetor adjustments. It compensates for
different fuels, altitude, humidity, temperature and clogged air filter.
X-Torq®
Delivers lower fuel consumption and reduced exhaust emission levels in accordance with the world´s most stringent environmental regulations.
RevBoost™
Rapid acceleration and higher chain speed for best limbing performance.
Flip-up tank cap
The flip-up tank cap is easy to open and close when refueling.
Specifications
Lubricant
Oil tank volume
0.7 US pint
Oil pump type
Adjustable flow
Oil pump capacity Max
15 ml/min
Oil pump capacity Min
6 ml/min
Vibration
Equivalent vibration level (ahv, eq) front handle
2.4 m/s²
Equivalent vibration level (ahv, eq) rear handle
3.1 m/s²
Overall dimensions
Weight (excl. cutting equipment)
13.45 lbs
Dimensions
Weight (excl. cutting equipment)
13.45 lbs
Equipment
Recommended bar length, max
28 in
Recommended bar length, min
15 in
Chain pitch
3/8"
Chain speed at max power
69.9 fts
Chain speed at 133% of maximum engine power speed
92.85 fts
Engine
Cylinder displacement
59.8 cm³
Cylinder displacement
3.65 cu.inch
Power output
4.7 hp
Maximum power speed
9600 rpm
Fuel tank volume
1.4 US pint
Idling speed
2800 rpm
Spark plug
NGK CMR6H
Electrode gap
0.02 in
Torque, max.
3.65 Nm
Fuel consumption
494 g/kWh
Sound and Noise
Sound power level, guaranteed (LWA)
118 dB(A)
Sound power level, measured
116 dB(A)
Sound pressure level at operators ear
106 dB(A)
