Features
AutoTune
AutoTune gives optimal engine performance throughout automatic engine setting.
No time spent on carburetor adjustments. It compensates for
different fuels, altitude, humidity, temperature and clogged air filter.
X-Torq®
Delivers lower fuel consumption and reduced exhaust emission levels in accordance with the world´s most stringent environmental regulations.
RevBoost™
Rapid acceleration and higher chain speed for best limbing performance.
Air Injection
Centrifugal air cleaning system removes larger dust and debris particles before reaching the air filter. This results in reduced air filter cleanings and improved engine life.
Specifications
Lubricant
Oil tank volume 0.7 US pint
Oil pump type Adjustable flow
Oil pump capacity Max 15 ml/min
Oil pump capacity Min 6 ml/min
Vibration
Equivalent vibration level (ahv, eq) front handle 2.4 m/s²
Equivalent vibration level (ahv, eq) rear handle 3.1 m/s²
Overall dimensions
Weight (excl. cutting equipment) 13.01 lbs
Dimensions
Weight (excl. cutting equipment) 13.01 lbs
Equipment
Recommended bar length, max 28 in
Recommended bar length, min 15 in
Chain pitch 3/8"
Chain speed at max power 69.9 fts
Chain speed at 133% of maximum engine power speed 92.85 fts
Engine
Cylinder displacement 59.8 cm³
Cylinder displacement 3.65 cu.inch
Power output 4.7 hp
Maximum power speed 9600 rpm
Fuel tank volume 1.4 US pint
Idling speed 2800 rpm
Spark plug NGK CMR6H
Electrode gap 0.02 in
Torque, max. 3.65 Nm
Fuel consumption 494 g/kWh
Sound and Noise
Sound power level, guaranteed (LWA) 118 dB(A)
Sound power level, measured 116 dB(A)
Sound pressure level at operators ear 106 dB(A)
