Features
X-Torq®
Delivers lower fuel consumption and reduced exhaust emission levels in accordance with the world´s most stringent environmental regulations.
Flip-up tank cap
The flip-up tank cap is easy to open and close when refueling.
AutoTune
AutoTune gives optimal engine performance throughout automatic engine setting.
No time spent on carburetor adjustments. It compensates for
different fuels, altitude, humidity, temperature and clogged air filter.
Air Injection
Centrifugal air cleaning system removes larger dust and debris particles before reaching the air filter. This results in reduced air filter cleanings and improved engine life.
Specifications
Lubricant
Oil tank volume 0.57 US pint
Oil pump capacity Max 12 ml/min
Oil pump capacity Min 5 ml/min
Vibration
Equivalent vibration level (ahv, eq) front handle 2.8 m/s²
Equivalent vibration level (ahv, eq) rear handle 3.7 m/s²
Overall dimensions
Weight (excl. cutting equipment) 10.8 lbs
Dimensions
Weight (excl. cutting equipment) 10.8 lbs
Equipment
Recommended bar length, max 20 in
Recommended bar length, min 13 in
Chain pitch .325"
Chain speed at max power 60.7 fts
Chain speed at 133% of maximum engine power speed 80.71 fts
Engine
Cylinder displacement 50.1 cm³
Cylinder displacement 3.06 cu.inch
Power output 3.35 hp
Maximum power speed 9600 rpm
Fuel tank volume 1.1 US pint
Idling speed 2800 rpm
Spark plug NGK CMR6H
Electrode gap 0.02 in
Torque, max. 2.69 Nm
Fuel consumption 424 g/kWh
Sound and Noise
Sound power level, guaranteed (LWA) 116 dB(A)
Sound power level, measured 114 dB(A)
Sound pressure level at operators ear 106 dB(A)
