Features
Air Injection
Centrifugal air cleaning system removes larger dust and debris particles before reaching the air filter. This results in reduced air filter cleanings and improved engine life.
X-Torq®
Delivers lower fuel consumption and reduced exhaust emission levels in accordance with the world´s most stringent environmental regulations.
LowVib®
System designed to reduce vibration levels to the operator, which lessens fatigue.
Adjustable oil pump
Allows you to control oil flow depending on application and weather conditions.
Specifications
Lubricant
Oil tank volume 0.7 US pint
Oil pump type Automatic
Oil pump capacity Max 17 ml/min
Oil pump capacity Min 6 ml/min
Vibration
Equivalent vibration level (ahv, eq) front handle 3.5 m/s²
Equivalent vibration level (ahv, eq) rear handle 4.5 m/s²
Overall dimensions
Weight (excl. cutting equipment) 12.79 lbs
Dimensions
Weight (excl. cutting equipment) 12.79 lbs
Equipment
Recommended bar length, max 24 in
Recommended bar length, min 13 in
Chain pitch 3/8"
Chain speed at max power 65.62 fts
Chain speed at 133% of maximum engine power speed 87.27 fts
Engine
Cylinder displacement 60.3 cm³
Cylinder displacement 3.68 cu.inch
Power output 3.62 hp
Maximum power speed 9000 rpm
Fuel tank volume 0.9 US pint
Idling speed 2700 rpm
Spark plug Champion RCJ7Y, NGK BPMR7A
Electrode gap 0.02 in
Torque, max. 3.4 Nm
Fuel consumption 437 g/kWh
Sound and Noise
Sound power level, guaranteed (LWA) 114 dB(A)
Sound power level, measured 112 dB(A)
Sound pressure level at operators ear 104 dB(A)
