Features
Air Injection
Centrifugal air cleaning system removes larger dust and debris particles before reaching the air filter. This results in reduced air filter cleanings and improved engine life.
X-Torq®
Delivers lower fuel consumption and reduced exhaust emission levels in accordance with the world´s most stringent environmental regulations.
Quick-release air filter
Facilitates cleaning and replacement of the air filter.
Ergonomic rear handle
Increased comfort with soft inlay, ergonomic trigger and asymmetrical handle.
Specifications
Dimensions
Weight (excl. cutting equipment) 10.8 lbs
Engine
Cylinder displacement 50.2 cm³
Cylinder displacement 3.06 cu.inch
Power output 3.2 hp
Maximum power speed 9000 rpm
Fuel tank volume 0.95 US pint
Idling speed 2700 rpm
Spark plug NGK BPMR7A, Champion RCJ7Y
Electrode gap 0.02 in
Torque, max. 2.6 Nm
Fuel consumption 504 g/kWh
Equipment
Recommended bar length, max 20 in
Recommended bar length, min 13 in
Chain pitch .325"
Chain speed at max power 56.76 fts
Chain speed at 133% of maximum engine power speed 75.46 fts
Lubricant
Oil tank volume 0.55 US pint
Oil pump type Fixed flow
Oil pump capacity Max 13 ml/min
Oil pump capacity Min 13 ml/min
Overall dimensions
Weight (excl. cutting equipment) 10.8 lbs
Sound and Noise
Sound power level, guaranteed (LWA) 115 dB(A)
Sound power level, measured 113 dB(A)
Sound pressure level at operators ear 104 dB(A)
Vibration
Equivalent vibration level (ahv, eq) front handle 3.1 m/s²
Equivalent vibration level (ahv, eq) rear handle 4.9 m/s²
