Features
Smart Start®
The engine and starter have been designed so the machine starts quickly with minimum effort.
Air Injection
Centrifugal air cleaning system removes larger dust and debris particles before reaching the air filter. This results in reduced air filter cleanings and improved engine life.
X-Torq®
Delivers lower fuel consumption and reduced exhaust emission levels in accordance with the world´s most stringent environmental regulations.
Quick-release air filter
Facilitates cleaning and replacement of the air filter.
Specifications
Lubricant
Oil tank volume 0.53 US pint
Oil pump type Fixed flow
Oil pump capacity Max 13 ml/min
Oil pump capacity Min 13 ml/min
Vibration
Equivalent vibration level (ahv, eq) front handle 2.5 m/s²
Equivalent vibration level (ahv, eq) rear handle 3.2 m/s²
Overall dimensions
Weight (excl. cutting equipment) 17.5 lbs
Dimensions
Weight (excl. cutting equipment) 17.5 lbs
Equipment
Recommended bar length, max 18 in
Recommended bar length, min 13 in
Chain pitch .325"
Chain gauge 0.05 in
Chain speed at max power 56.76 fts
Chain speed at 133% of maximum engine power speed 75.46 fts
Engine
Cylinder displacement 40.9 cm³
Cylinder displacement 2.49 cu.inch
Power output 2.41 hp
Maximum power speed 9000 rpm
Fuel tank volume 0.78 US pint
Idling speed 2900 rpm
Spark plug Champion RCJ7Y, NGK BPMR7A
Electrode gap 0.02 in
Torque, max. 2.16 Nm
Fuel consumption 510 g/kWh
Sound and Noise
Sound power level, guaranteed (LWA) 114 dB(A)
Sound power level, measured 112 dB(A)
Sound pressure level at operators ear 102 dB(A)
