Features
Air Injection
Centrifugal air cleaning system removes larger dust and debris particles before reaching the air filter. This results in reduced air filter cleanings and improved engine life.
Adjustable oil pump
Allows you to control oil flow depending on application and weather conditions.
Quick-release air filter
Facilitates cleaning and replacement of the air filter.
Magnesium crankcase
Sturdily built crankcase withstands high rpms and tough professional use, ensuring a long service life.
Specifications
Lubricant
Oil tank volume 1.06 US pint
Oil pump type Automatic
Oil pump capacity Max 20 ml/min
Oil pump capacity Min 15 ml/min
Vibration
Equivalent vibration level (ahv, eq) front handle 6.5 m/s²
Equivalent vibration level (ahv, eq) rear handle 10.2 m/s²
Overall dimensions
Weight (excl. cutting equipment) 17.4 lbs
Dimensions
Weight (excl. cutting equipment) 17.4 lbs
Equipment
Recommended bar length, max 36 in
Recommended bar length, min 18 in
Chain pitch 3/8"
Chain gauge 0.058 in
Chain speed at max power 64.3 fts
Chain speed at 133% of maximum engine power speed 85.63 fts
Engine
Cylinder displacement 93.6 cm³
Cylinder displacement 5.71 cu.inch
Power output 6.97 hp
Maximum power speed 9600 rpm
Fuel tank volume 1.9 US pint
Idling speed 2500 rpm
Spark plug Champion RCJ6Y
Electrode gap 0.02 in
Torque, max. 5.9 Nm
Fuel consumption 470 g/kWh
Sound and Noise
Sound power level, guaranteed (LWA) 115 dB(A)
Sound power level, measured 114 dB(A)
Sound pressure level at operators ear 102 dB(A)
