Features
Air Injection
Centrifugal air cleaning system removes larger dust and debris particles before reaching the air filter. This results in reduced air filter cleanings and improved engine life.
X-Torq®
Delivers lower fuel consumption and reduced exhaust emission levels in accordance with the world´s most stringent environmental regulations.
Combined choke/stop control
Allows for easier starting and reduces the risk of engine flooding.
LowVib®
System designed to reduce vibration levels to the operator, which lessens fatigue.
Air Purge
Removes air from carburetor and fuel system for easy starting.
Inertia activated chain brake
Reduces the likelihood of injury due to kickback.
Specifications
Lubricant
Oil tank volume 0.09 US pint
Oil pump type Fixed flow
Oil pump capacity Max 8 ml/min
Oil pump capacity Min 8 ml/min
Vibration
Equivalent vibration level (ahv, eq) front handle 2.1 m/s²
Equivalent vibration level (ahv, eq) rear handle 2.7 m/s²
Overall dimensions
Weight (excl. cutting equipment) 10.3 lbs
Dimensions
Weight (excl. cutting equipment) 10.3 lbs
Equipment
Recommended bar length, max 16 in
Recommended bar length, min 13 in
Chain pitch 3/8"
Chain speed at max power 53.48 fts
Chain speed at 133% of maximum engine power speed 71.19 fts
Engine
Cylinder displacement 38.2 cm³
Cylinder displacement 2.3 cu.inch
Power output 2 hp
Maximum power speed 9000 rpm
Fuel tank volume 0.14 US pint
Idling speed 3000 rpm
Spark plug Champion RCJ7Y
Electrode gap 0.02 in
Sound and Noise
Sound power level, guaranteed (LWA) 113 dB(A)
Sound pressure level at operators ear 100.7 dB(A)
Vibration
Equivalent vibration level (ahv, eq) front handle 2.1 m/s²
Equivalent vibration level (ahv, eq) rear handle 2.7 m/s²
