Air Induction Mowing Technology
Air is drawn from the top and bottom of the deck, improving grass lift and delivering a superior cut.
Worry free performance with maintenance free, integrated zero-turn transmissions.
Convenient deck lift
The deck lift system is spring assisted for ease of use and conveniently located within easy reach of the operator.
Rugged frame and casters
The robust frame and casters ensure durability and reduced chassis flex.
Kawasaki engines offer smooth, quiet, reliable power. Heavy-duty components offer long life and electric start is standard.
Removable foot plate
The unique tube style chassis features a removable foot pan for easy access to the top of the cutting deck.
Anti-slip foot area
The footrest area incorporates generous non-slip surfaces for safe and comfortable use.
The integrated front guard/ bumper offers bold styling while protecting the nose of the unit. An optional bright LED headlight kit can easily be added, providing improved visability in dark conditions.
Rubber bellows offer a refined look and prevent debris and moisture from entering the control system.
Automatic park brake system
The new patent pending park brake system automatically activates or deactivates as the steering levers are moved outward or inward, freeing the user of the task.
Rear engine guard
The rear guard protects the engine from impact as well as limits access to hot surfaces for safety.
Ergonomic control panel
The ergonomic control panel places everything conveniently at your fingertips.
Homeowner Warranty 3 Years
Productivity 2.8 acres/hr
Speed forward max 6.5 mph
Speed forward min 0 mph
Cutting width 54 in
Cutting methods 3-in-1 Mulch/Rear Bag/Side Discharge Capable
Cutting deck material Steel
Deck thickness 12 gauge
Blade engagement Electric clutch
Blades 3 pcs
Blade-tip speed 18500 fpm
Anti-scalp wheels 4
Deck lifting system Manual, hand operated
Powder-coated cutting deck Yes
Spindle/mandrel type Cast Aluminum
Greasable mandrels Yes
Deck Wash Port Yes
Cutting height, min (approximate) 1.5 in
Cutting height, max (approximate) 4 in
Tire size, front Diameter 11 in
Tire size, front Diameter wheel 11 in
Transmission type Hydrostatic
Transmission manufacturer Hydro-Gear
Transmission model EZT
Motor/engine manufacturer Kawasaki
Engine name FR Series
Power 23 hp
Cylinder displacement 44.3 cu.inch
Engine cooling Air
Air filter type Standard
Power/fuel type Gasoline
Engine lubrication type Pressure
Oil filter Yes
Fuel tank volume (with reserve) 3.5 gal (US)
Fuel tank location Side (Single)
Seat material Vinyl
Seat spring Yes
Hour meter Yes
Cup holder Yes
Seat type Vinyl with built in slide
