6-inch Wide Caster Wheels
Durable 6-inch wide front casters with pneumatic tires provide long life and are easy on turf.
ClearCut™ fabricated cutting deck
The new fabricated design with ClearCut bumper features welded 10 gauge steel construction with additional welded reinforcement strips for maximum durability
Removable foot pan
Removable foot pan for easy access to deck belt pulleys, spindles and clean-up.
Pedal-assisted cutting deck lift
Ergonomically designed deck lifting system offers precise cutting height adjustment. Easy and quick adjustment from the operator’s seat.
Thick cushions and EVC (elastomeric vibration control) provide unsurpassed comfort for the operator. The two tone vinyl covers are replaceable in the event of damage.
2'' x 3'' tube chassis combined with large rear and front tires provide superior strength and improved ride quality.
Durable cutting deck
The heavy-duty fabricated cutting deck features twin sheets of 11 gauge steel for added support for spindles and increased overall strength.
Longer life due to premium integrated zero-turn transmissions featuring charge-pumps, larger drive axles and expansion tanks.
Cast Aluminum Deck Spindles
Durable blade spindles with aluminum housings for effective heat dissipation.
Hour meter with service minder
Indicates when it's time to service your mower.
Easy-access service points
Oil and filter maintenance, hydraulic drive system components/adjustment, electrical system and battery are all within easy reach so you can quickly get back to being productive.
Dual levers with foam-padded hand grips and viscous dampers that reduce vibration, create a comfortable operator experience.
Comfort & Support
The comfortable high back seat features standard arm rests.
The easily accessible adjustment allows fine-tuning of straight line tracking without tools.
Zero-turn steering system
Individual, hydraulic wheel-drive provides very precise maneuvering and allows the mower to rotate around its own axis, without any turning radius.
Premimum engine from Kohler features commercial grade construction and quality components for long life and dependable mowing performance.
Oversized Tube Frame
The oversized welded frame offers improved structural integrity, operator comfort and ride quality.
Homeowner Warranty: 4 years or 400 hours (whichever occurs first)
Commercial Warranty: 4 years or 400 hours (whichever occurs first)
Productivity: 3.7 acres/hr
Speed forward: max 8 mph
Speed forward: min 0 mph
Cutting width: 48 in
Cutting deck type: 11-gauge fabricated
Cutting deck material: Steel
Deck thickness: 11 gauge
Blade engagement: Electromagnetic clutch
Blades: 3 pcs
Blade-tip speed: 18500 f pm
Anti-scalp wheels: 3
Deck lifting system: Manual, foot assisted
Powder-coated cutting deck: Yes
Spindle/mandrel type: Cast Aluminum
Deck Wash Port: Yes
Cutting height, min: (approximate) 1.5 in
Cutting height, max: (approximate) 4.5 in
Base machine, length: 75.5 in
Base machine, height (ROPS down): 42 in
Tire size, front: Width 6.5 in
Tire size, front: Diameter 6 in
Tire size, front: Diameter wheel 13 in
Transmission type: Hydrostatic
Transmission manufacturer: Hydro-Gear
Transmission model: ZT 3100
Pump displacement: 10 cm³
Fan-cooled pumps: Yes
Motor/engine manufacturer: Kohler
Engine name: 7000 Series
Power: 23 hp
Cylinder displacement: 44.2 cu.inch
Engine cooling: Air
Air filter type: Standard
Power/fuel type: Gasoline
Engine lubrication type: Pressure
Oil filter: Yes
Fuel tank volume (with reserve): 5 gal (US)
Fuel tank location: Side (Single)
Seat material: Vinyl
Seat spring: Yes
Seat back height: High
Hour meter: Yes
Cup holder: Yes
Seat type: Standard high back, arm rests
