Features
Intuitive controls
The choke and purge are easy to reach and understand.
Auto return stop switch
When the machine is turned off, the stop switch automatically returns to the start position for easier starting.
Stand alone starter
The stand alone starter makes it easy to change starter cord if needed.
X-Torq® engine
The X-Torq® engine design reduces harmful exhaust emissions by up to 60% and increases fuel efficiency by up to 20%.
Heavy duty edger head
The 90 degree edger head is designed for tough commercial use.
Efficient air filter
The efficient air filter provide less cost for service and less engine wear .
Specifications
Dimensions
Tube length 59.1 in
Tube diameter 0.9 in
Engine
Cylinder displacement 1.55 cu.inch
Power output 1.34 hp
Maximum power speed 8500 rpm
Fuel tank volume 17.3 fl oz
Fuel consumption 600 g/kWh
Idling speed 3000 rpm
Spark plug NGK BPMR8Y
Lubricant
Lubricant type (bevel gear) Mineral grease
Sound and Noise
Sound pressure level at operators ear 94 dB(A)
Transmission
Drive gear angle 30 °
Vibration
Equivalent vibration level (ahv, eq) front handle 4.2 m/s²
Equivalent vibration level (ahv, eq) rear handle 9.1 m/s²
