Features
ENGINE FEATURES
- NEW! Fuel efficient Kawasaki® FT730V EFI engine option
- Dual-stage industrial air cleaner extends engine service life (Vanguard™ 810 Model)
- Patented advanced debris management system (Briggs & Stratton® Commercial Series Models)
- Vortical air filtration system (Kawasaki® FT730V EFI Models)
- Rugged 5.5-gallon fuel tank
- Heavy-duty integrated rear bumper protects engine compartment
MOWER DECK
- iCD™ Cutting System
- Foot-operated deck lift, with adjustable pedal, can change cut height in 1/4" increments from 1.5"- 5"
- Cast aluminum greaseable spindles with greaseable bearings for longer usable life
SUSPENSION & DRIVE TRAIN
- Patented suspension system enables you to mow rougher ground faster with a consistent cut quality allowing you to be more productive
- Dual, commercial Hydro-Gear® ZT-3400® Transaxles feature 7" cooling fans that assist with repelling debris
SPEED
- Ground speed up to 10 mph
OPERATOR SYSTEMS
- Ergonomic control panel features cup holder and fuel gauge for operator convenience
- Comfortable thicker 1" tubular steering control levers
- Flip-up seat for easy access
- Mid-back seat features enhanced bolstering in seat, with armrests for added comfort, and offers adjustable fore and aft positioning
- Large springs under the seat mount provides additional operator comfort
- Removable floor pan provides easy access
Specifications
| Engine Brand | Briggs & Stratton® Commercial Series |
| Engine Power Rating * | 27 |
| Displacement (cc) | 810 |
| PTO | Electric |
| Cylinders | 2 |
| Starter | Electric |
| Fuel Tank Capacity (gal) | 5.5 |
| Cutting Width (in) | 52 |
| Cutting Height (in) | 1.5 - 5 |
| Spindles | Aluminum |
| Deck Construction | iCD Cutting System™ |
| Suspension | Adjustable front and rear coil-over-shocks with pivoting front axle |
| Transmission | Dual, commercial Hydro-Gear ZT-3200® Transaxles with 7" cooling fans |
| Drive Axles (in) | 1.125 |
| Caster Tires (in) | 13 X 5-6 |
| Drive Tires (in) | 22 X 11-10 |
| Ground Speed-Fwd (mph) | 0-10 |
| Ground Speed-Rev (mph) | 0-5 |
| Overall Length (in) | 81 |
| Overall Width (in) Deflector Down/Deflector Up | 66.75/56.5 |
| Dry Weight (lbs) | 1059 |
| Seat Package | Premium adjustable seat with arm rests |
| Certified Roll-over Protection System | Standard, 180° foldable |
| Controls / Safety Group | Seat activated engine kill, clutch safety switch, neutral and parking brake safety circuit/adjustable twin steering controls. |
| Parking Brake / Safety Circuit | Internal transaxles |
