Features
ENGINE FEATURES
- Oil Guard™ System on Vanguard™ BIG BLOCK™ Engine options
- Two-stage industrial air-cleaner
- Easy-to-use oil drain
- Rugged twin 5.5-gallon fuel tanks (11 gallons total)
- Heavy-duty integrated rear bumper protects engine compartment
MOWER DECK
- iCD™ Cutting System
- 2-belt drive system that improves belt life and is more dependable
- Foot-operated deck lift, with adjustable pedal, can change cut
height in 1/4" increments from 1.5"- 5" - Hercules™ II spindles with greaseable bearings for longer usable life
SUSPENSION & DRIVE TRAIN
- Patented suspension system enables you to mow uneven terrain faster
with a consistent cut quality allowing you to be more productive - Dual commercial Hydro-Gear® ZT-5400 Powertrain® Transaxles feature
9" cooling fans that assist with repelling debris - Large turf friendly 26" rear tires for increased traction and performance
SPEED
- Ground speed up to 12 mph
OPERATOR SYSTEMS
- Ergonomic control panels feature a cup-holder, storage
compartment and fuel gauges for operator convenience - Comfortable thicker 1" tubular steering control levers
- Premium high-back seat features enhanced bolstering, with adjustable
cushioned armrests for added comfort, and offers adjustable fore and aft positioning - Removable floor pan provides easy access compartment
Specifications
| Engine Brand | Vanguard™ BIG BLOCK™ EFI with Oil Guard |
| Engine Power Rating * | 37 |
| Displacement (cc) | 993 |
| PTO | Electric |
| Cylinders | 2 |
| Starter | Electric |
| Fuel Tank Capacity (gal) | 11 |
| Cutting Width (in) | 72 |
| Cutting Height (in) | 1.5 - 5 |
| Spindles | Hercules™ II Cast-Iron |
| Deck Construction | iCD™ Cutting System |
| Suspension | Adjustable rear coil-over-shocks and front independent adjustable coil-over-shocks |
| Transmission | Dual Commercial Hydro-Gear® ZT-5400 Powertrain® transaxles with 9" cooling fans |
| Drive Axles (in) | 1.375 |
| Caster Tires (in) | 13 X 6.5 - 6 |
| Drive Tires (in) | 26 X 12-12 |
| Ground Speed-Fwd (mph) | 0-12 |
| Ground Speed-Rev (mph) | 0-5 |
| Overall Length (in) | 84.5 |
| Overall Width (in) Deflector Down/Deflector Up | 85.75 / 76.5 |
| Dry Weight (lbs) | 1511 |
| Seat Package | Suspension Seat |
| Instrumentation/Hour Meter | |
| Certified Roll-over Protection System | Standard, 165° foldable |
| Controls / Safety Group | Seat activated engine kill, clutch safety switch, neutral and parking brake safety circuit, adjustable twin steering controls |
| Parking Brake / Safety Circuit | Internal transaxles |
