Features
ENGINE FEATURES
- Oil Guard™ System on Vanguard™ 810 EFI engine options
- Dual-stage industrial air-cleaner extends engine service life
- Rugged twin 5.5-gallon fuel tanks (11 gallons total)
- Heavy-duty integrated rear bumper protects engine compartment
MOWER DECK
- iCD™ Cutting System
- 2-belt drive system that improves belt life and is more dependable
- Foot-operated deck lift, with adjustable pedal, can change cut height in 1/4" increments from 1.5"- 5"
- Features greaseable cast-iron spindles with greaseable bearings for longer usable life
SUSPENSION & DRIVE TRAIN
- Patented suspension system enables you to mow uneven terrain faster with a consistent cut quality allowing you to be more productive
- Dual, commercial Hydro-Gear® ZT-4400™ Transaxles feature 8.3" cooling fans that assist with repelling debris
- Large turf friendly 24" rear tires for increased traction and performance
SPEED
- Ground speed up to 10 mph
OPERATOR SYSTEMS
- Ergonomic control panels feature a cup holder, storage compartment and fuel gauges for operator convenience
- Comfortable thicker 1" tubular steering control levers
- Flip-up seat for easy access
- Premium mid-back seat features enhanced bolstering, with adjustable cushioned armrests for added comfort, and offers adjustable fore and aft positioning
- Removable floor pan provides easy access compartment
Specifications
| MODEL | 5901588 |
| Engine Brand | Kawasaki® FX801V |
| Engine Power Rating * | 25.5 gross hp |
| Displacement (cc) | 852 |
| PTO | Electric |
| Cylinders | 2 |
| Starter | Electric |
| Fuel Tank Capacity (gal) | 11 |
| Cutting Width (in) | 61 |
| Cutting Height (in) | 1.5 - 5 |
| Spindles | Cast-iron greaseable |
| Deck Construction | iCD™ Cutting System |
| Suspension | Adjustable rear coil-over-shocks and front independent adjustable coil-over-shocks |
| Transmission | Dual, commercial Hydro-Gear® ZT-4400™ Transaxles with 8.3" cooling fans |
| Drive Axles (in) | 1.375 |
| Caster Tires (in) | 13 x 6.5-6 |
| Drive Tires (in) | 24 x 12-12 |
| Ground Speed-Fwd (mph) | 0-10 |
| Ground Speed-Rev (mph) | 0-5 |
| Overall Length (in) | 82.5 |
| Overall Width (in) Deflector Down/Deflector Up | 78 / 61.5 |
| Dry Weight (lbs) | 1295 |
| Seat Package | Premium mid-back |
| Certified Roll-over Protection System | Standard, 180° foldable |
| Instrumentation | Fuel level gauge in each tank, hour meter |
| Controls / Safety Group | Seat activated engine kill, clutch safety switch, neutral and parking brake safety circuit/adjustable twin steering controls |
| Parking Brake / Safety Circuit | Internal Transaxles |
