Features
ENGINE FEATURES
- Patented advanced debris management system (Briggs & Stratton® Commercial Series Models)
- Two-stage industrial remote air-cleaner (Kawasaki® Models)
- Easy-to-use oil drain
- Twin 4-gallon rugged, impact resistant fuel tanks with switch for fuel source
- Extra large filler neck• Heavy-duty integrated rear bumper protects engine compartment
MOWER DECK
- 36" 10-gauge fabricated
- Foot-operated deck lift, with adjustable pedal, can change cut height in .25" increments from 1.5"- 4.5"
- Aluminum greaseable spindles
DRIVE TRAIN
- Dual commercial Hydro-Gear® ZT-3100® Transaxles feature 7" cooling fans that assist with repelling debris
- Dual hydro fluid reservoirs and filters
- Flat-free caster tires
SPEED
- Ground speed up to 7 mph
OPERATOR SYSTEMS
- Ergonomic control panels and fuel gauges for operator convenience
- Mid-back adjustable seat with padded arm rests
- Energy absorbing isolation bumpers under the seat mount provides additional operator comfort
- Flip-up seat
- Adjustable steel padded control arms
- Removable floor pan provides easy access
Specifications
| MODEL | 5901548 |
| Engine Brand | Briggs & Stratton® Commercial Series |
| Engine Power Rating * | 25 gross hp |
| Displacement (cc) | 724 |
| PTO | Electric |
| Cylinders | 2 |
| Fuel Tank Capacity (gal) | 8 |
| Cutting Width (in) | 36 |
| Cutting Height (in) | 1.5 - 4.5 |
| Spindles | Aluminum |
| Drive Axles (in) | 1.375 Tapered |
| Caster Tires (in) | 11 x 4-5 Flat-free |
| Drive Tires (in) | 20 x 7-10 |
| Ground Speed-Fwd (mph) | 0-7 |
| Ground Speed-Rev (mph) | 0-4 |
| Overall Length (in) | 74 |
| Overall Width (in) Deflector Down/Deflector Up | 49.5/40.5 |
| Dry Weight (lbs) | 709 |
| Seat Package | Mid-back adjustable seat with arm rests |
| Instrumentation/Hour Meter | Fuel level gauge in each tank, hour meter |
| Certified Roll-over Protection System | N/A |
| Controls / Safety Group | Seat activated engine kill, clutch safety switch, neutral and parking brake safety circuit, adjustable twin steering controls |
| Parking Brake / Safety Circuit | Internal transaxle |
| Starter | Electric |
| Transmission Type | Dual commercial Hydro-Gear® ZT-3100® Transaxles with 7" cooling fans |
| Deck Construction | Fabricated 10-gauge |
