Features
ENGINE FEATURES
- Oil Guard™ System on Vanguard™810 EFI engine options
- Two-stage industrial air-cleaner
- Easy-to-use oil drain
- Twin 5.5-gallon rugged, impact resistant fuel tanks with switch for fuel source (11 gallons total)
- Heavy-duty integrated rear bumper protects engine compartment.
MOWER DECK
- iCD™ Cutting System
- 2-belt drive system that improves belt life and is more dependable
- Foot-operated deck lift, with adjustable pedal, can change cut height in 1/4" increments from 1.5"- 5"
- Cast-iron greaseable spindles with greaseable bearings for longer usable life, 1" shaft with top access grease fitting, 6-bolt 8" flange design adds strength and greater dispersal of energy to deck assembly
DRIVE TRAIN
- Dual commercial Hydro-Gear® ZT-5400 Powertrain® Transaxles feature 9" cooling fans that assist with repelling debris
- Large turf friendly 24" rear tires for increased traction and performance
- Flat-free caster tires
SPEED
- Ground speed up to 10 mph
OPERATOR SYSTEMS
- Ergonomic control panels feature a cup-holder, storage compartment and fuel gauges for operator convenience
- Comfortable thicker 1" tubular steering control levers
- Suspension seat in our premium mid-back design features enhanced bolstering, with adjustable cushioned armrests for added comfort, manually adjusts to operator's height and weight in addition to fore and aft positioning for a custom-like fit
- Flip-up seat
- Removable floor pan provides easy acces
Specifications
| MODEL | 5901653 |
| Engine Brand | Vanguard™ 810 EFI with Oil Guard |
| Engine Power Rating * | 28 gross hp |
| Displacement (cc) | 810 |
| PTO | Electric |
| Cylinders | 2 |
| Starter | Electric |
| Fuel Tank Capacity (gal) | 11 |
| Cutting Width (in) | 61 |
| Cutting Height (in) | 1.5 - 6 |
| Spindles | Cast-Iron |
| Deck Construction | iCD™ Cutting System |
| Suspension | N/A |
| Transmission | Dual commercial Hydro-Gear® ZT-5400 Powertrain® Transaxles with 9" cooling fans |
| Drive Axles (in) | 1.375 Tapered |
| Caster Tires (in) | 13 x 6.5-6 Flat-free |
| Drive Tires (in) | 24 x 12-12 |
| Ground Speed-Fwd (mph) | 0-10 |
| Ground Speed-Rev (mph) | 0-5 |
| Overall Length (in) | 79 |
| Overall Width (in) Deflector Down/Deflector Up | 76 / 63 |
| Dry Weight (lbs) | 1190 |
| Seat Package | Premium suspension mid-back |
| Hour Meter | Fuel level gauge in each tank, hour meter |
| Certified Roll-over Protection System | Standard, 165° foldable |
| Controls / Safety Group | Seat activated engine kill, clutch safety switch, neutral and parking brake safety circuit, adjustable twin steering controls |
| Parking Brake / Safety Circuit | Internal transaxle |
