Features
- Ground speed up to 8 mph
- Rugged 5.5-gallon fuel tank
- Serviceable Hydro-Gear ZT-2800
- Fabricated deck with reinforced top, corners, side skirts and leading edge
- Turf-friendly 20" drive and 11" caster tires
Specifications
Engine Brand | Kawasaki® FR651V |
Displacement (cc) | 651 |
Cylinders | 2 |
Fuel Tank Capacity (gal) | 5.5 |
Cutting Height (in) | 1.5 - 4.5 |
Deck Construction | 10-guage fabricated |
Transmission | Dual Hydro-Gear® ZT-2800® transaxles with 7" cooling fans |
Caster Tires (in) | 11 X 4-5 pneumatic |
Ground Speed-Fwd (mph) | 0-8 |
Overall Length (in) | 69.875 |
Dry Weight (lbs) | 753 |
Controls / Safety Group | Adjustable twin fold out 1" tubular steering levers with comfort grip |
Engine Power Rating * | 21.5 gross hp |
PTO | Electric |
Starter | Electric |
Cutting Width (in) | 48 |
Spindles | Aluminum |
Suspension | Front and rear adjustable dual coil-over shocks |
Drive Axles (in) | 1.125 |
Drive Tires (in) | 20 X 10-10 |
Ground Speed-Rev (mph) | 0-4 |
Overall Width (in) Deflector Down/Deflector Up | 59 / 53 |
Seat Package | Mid-back seat with arm rests |
Parking Brake / Safety Circuit | Internal transaxles |
