- NEW! Oil Guard System on Vanguard™ BIG BLOCK EFI engine options. Save 60% on oil maintenance per season per unit!**
- CC™ Centralized Control handles for natural, ergonomic position with improved comfort and narrower stance for hand protection from scrapes & cuts.
- Easy mowing with electric starter with cruise control bar for desired speeds.
- Heavy-duty construction with two layers of steel running the entire width for strength & lap welded corners for dent resistance.
- Big 20" tires for climbing over curbs and rough terrains, reducing deck bounce for consistent cut.
- Commercial-grade transmission & the same muscle driving our heavier, commercial zero turn mower line.
- One-hand deck lift system and gauge for accurately adjusting cutting height from 1.5 to 4.75 inches.
|Engine Brand||Vanguard™ 810 EFI with Oil Guard|
|Power Rating (hp)*||28 gross hp|
|Fuel Tank Capacity (gal)||5|
|Cutting Width (in)||52|
|Cutting Height (in)||1.5 - 4.75|
|Deck Construction||Fabricated 10-gauge|
|Transmission||Dual commercial Hydro-Gear® ZT-3100® transaxles with 7" cooling fans|
|Drive Axles (in)||1|
|Caster Tires (in)||11 x 4-5 Flat-free|
|Drive Tires (in)||20 x 8-10|
|Ground Speed-Fwd (mph)||0-7|
|Ground Speed-Rev (mph)||0-3|
|Overall Length (in)||Standard: 78.75, CC™: 75|
|Overall Width (in) Deflector Down/Deflector Up||67 / 57|
|Dry Weight (lbs)||814|
|Rollover Protection System (ROPS)||N/A|
|Instrumentation||hour meter, speed indicator|
|Parking Brake/Safety Circuit||Internal transaxle|
|Safety Group/Controls||Operator presence, centralized foot activated neutral pedals, neutral start safety circuit/CC™ (Centralized Controls) or standard controls|
