Features

200 lbs. Spyker Hopper
The Pathfinder XC™ FS2200 hopper will handle up to 200 lbs. of granular material providing over one acre of maximum coverage.

16 Gallons of Liquid Capacity
Covers a maximum of 1.4 acres between fill-ups.

Selectable Spray Width
The Pathfinder XC™ FS2200 allows the operator to select between two spray widths. A 3’ spray width is perfect for trim applications and narrow spaces. A 10’ broadcast spray is used for wide open spaces.

100% Stainless Steel Frame
Stainless steel resists corrosion from the granular and liquid chemicals distributed by the unit.

Best-in-Class Maneuverability
A low-friction sulky pivots on a ¾” tapered roller bearing for smooth movement. No mechanical steering assistance is required.

Compact Size
The Pathfinder XC™ FS2200 fits easily through a 36” gate, providing access to residential areas and condominium common areas.

Specifications

Engine Model GX200-URH2
Fuel Capacity - gal (L) 2.5 (9.5 L)
Fuel Shut-Off Valve Located on engine and below tank
Speed Low Gear: 3.5 mph (5.6 km/hr) High Gear: 5.0 mph (8.0 km/hr)
Rear Tires 13 x 6.50 - 6
Spreader Hopper Capacity (lbs.) 200
Sprayer Tank Capacity - gal (L) 16.0 (60.6)
Spray Rate Adjustable from 1/4 to 1/2 gallon per thousand square feet
Overall Width - in. (cm) 35.5 (90)
Dry Weight - lbs (kg) 450 (204)
Charging System N/A
Safety Interlock This machine is equipped with a neutral safety start module. To start the engine, the transmission must be in the neutral (N) position.
Belts, Tires, Brake Pads, Hoses, Battery Warranty Standard: 90 days Rental: 90 days
RPM Full Speed: 3750 RPM (No load) Idle: 1400 RPM
Fuel Type Regular unleaded gasoline, 87 octane or higher
Transmission Model Peerless 855 Series, coated for corrosion resistance
Front Tires 18 x 9.5 - 8, RV antifreeze added for ballast and traction
Spreader Model Spyker 220 Series
Spray Pump 2.0 gpm mechanically driven diaphragm pump
Nozzles Broadcast: Turbo FloodJet TF-VS5 Trim: Turbo TeeJet TT11004VP
Overall Length - in. (cm) 58.0 (147)
Overall Height - in. (cm) 49.0 (124)
Full Weight - lbs (kg) 640 (290)
Charging Capacity 670 (304)
