- The 31 gross-horsepower* Vanguard™ engine offers big performance along with a 3-year limited manufacturer’s warranty†.
- The F800X has a speed of up-to 10 mph and features a pivoting rear axle with a floating front frame, pillow block bearings on its control mounts, dual hydro pumps and wheell motors equipped with 7” mounted cooling fans.
- The iCD™ Cutting System comes with a 61” or 72” wide deck equipped with heavy-duty, cast-iron spindles.
- The electric deck lift makes cut-height adjustments easy.
- Quick access switches and quick release latches for the undercarriage and engine for easy maintenance.
- Premium suspension seat for adjustable comfort.
- Other features: twin six-gallon fuel tanks with integrated choke throttle, PTO and ignition switches; large, 24” flat-free drive tires; cup holder; and storage compartment.
|MODEL||5901236 w/ 5901238|
|Engine Power Rating *||31 gross hp|
|Fuel Tank Capacity (gal)||12|
|Cutting Width (in)||72|
|Cutting Height (in)||1.5 - 5|
|Deck Construction||iCD™ Cutting System|
|Transmission||Dual hydro pumps and wheel motors with 7" cooling fans|
|Drive Axles (in)||1.25|
|Drive Tires (in)||24 x 12-12|
|Ground Speed-Fwd (mph)||0-10|
|Ground Speed-Rev (mph)||0-5|
|Overall Length (in)||115.5|
|Overall Width (in) Deflector Down/Deflector Up||88 / 74|
|Dry Weight (lbs)||1677|
|Seat Package||Premium adjustable suspension seat|
|Certified Roll-over Protection System||Standard, 90° foldable|
|Parking Brake / Safety Circuit||Disk|
