New Electric Clutch
Proven to be among the most durable and reliable in the business, Exmark’s superior electric clutch technology allows for easier and faster belt servicing.
Standard 9” x 3.5-4” smooth-tread, semi-pneumatic front caster tires virtually eliminate tire repair.
Hour Meter Comes Standard
Improve maintenance records and track service intervals for longer life.
Patented Enhanced Control System (ECS)
Recent university tests showed landscape professionals prefer our control system to all others on the market.
An eco-friendly, lower cost fuel reduces operating expenses versus typical gas-powered mowers.
Full-floating UltraCut™ deck. Side discharge standard, with molded discharge chute and option to bag or mulch.
|Steering Control||Hydro drive with Enhanced Control System (ECS), forward/reverse, left/right or zero-turn.|
|Casters||.38" thick caster yoke arms|
|Front Caster Tires||9 x 3.5-4, smooth-tread, semi-pneumatic.|
|Drive Tires||16 x 7.5-8, 4-ply Turf Master®|
|Safety Package||Operator Presence Controls (OPC). Operator must have speed control lever in neutral and blades disengaged to leave operator's position without stopping engine|
|Parking Brake||Lever-actuated mechanical compression.|
|Electrical||12-volt battery with 15-amp alternator.|
|Engine Speed||3,600 rpm|
|Air Filter||Standard Engine Manufacturer's air filter|
|Drive Description||Twin Hydro-Gear variable-displacement pumps and twin high-efficiency Parker/Ross wheel-drive motors with 1\\" (2.54 cm) tapered shafts.|
|Speed||Infinitely variable speed selection from 0- 6.2 mph (10 kmph) forward, 0-2.2 mph (3.5 kmph) reverse.|
|PTO Engagement||Electromagnetic 105 ft-lbs clutch.|
|Fuel Capacity||5-gallon (18.9-L) fuel tank.|
|Drive Wheel Release||Allows unit movement without engine running.|
|Deck Lift||Manual lift with hairpin from hole to hole for position adjustment.|
|Fuel Type||Gas Carbureted|
|Deck Style||Floating Deck|
|Deck Style Description||Full-floating UltraCut Series 3, side discharge standard, with molded discharge chute and option to bag or mulch.|
|Width / Cutting Deck||52"|
|Deck Construction||10-gauge top that is formed and continuously seam welded, 7-gauge side skirt and 7-gauge welded spindle mounting locations for improved strength.|
|Cutting Heights||1.5" (3.8 cm) to 4.5" (11.4 cm) in 0.5" (1.3 cm) increments.|
|Blade Spindles||No maintenance, sealed and non-greasable spindles; 7.75"-diameter cutter housing with 25mm (.98") diameter spindle shaft and splined blade driver.|
|Blade Tip Speed||Approximately 18,500 fpm.|
|Blades||3 Blades at 18.00" Length|
|Width||64.3 in. (163.3 cm)|
|Length||75.9 in. (192.8 cm)|
|Height||42.0 in. (106.7 cm)|
