Tool-less Belt Removal
Deck and hydro belt can be installed without using any tools.
Adjustability of Platform
Platform design provides quick and easy 5-point adjustment without the use of tools, which delivers customized suspension response based on the operators personal preference.
Trailing arms help to eliminate side to side movement of platform, making operator feel more in control.
Lazer Z Performance
Same quality of cut, durability and performance of a Lazer Z but with added operator comfort.
New Level of Comfort
Comfort increases productivity. That’s why we designed a new, ergonomically advanced seat system featuring our exclusive Iso-Mount Seat Isolation System.
|Blade Spindles||No maintenance, sealed and non-greasable spindles; 7.75"-diameter cutter housing with 25mm (.98") diameter spindle shaft and splined blade driver.|
|Drive Tires||23 x 9.50-12, 4 ply Super Turf®|
|Tractor Frame||Unibody, welded, heavy-duty 1.5" x 3" tubular steel.|
|Steering Control||Hydraulically dampened twin levers, adjust fore and aft. Adjustable dampeners (3 positions) to customize drive responsiveness. Also adjustable to 2 height positions.|
|Front Caster Tires||13 x 5.0-6, smooth-tread, semi-pneumatic.|
|Parking Brake||Lever-actuated disc brake.|
|Seat||Deluxe, two-tone, bolstered suspension seat with Elastomeric Vibration Control material. Seat Isolation System for reduced vibration, to enhance ride of standard seat.|
|Electrical||12-volt battery with 20-amp alternator.|
|Engine Speed||3,750 rpm|
|Air Filter||Heavy-duty canister air filtration system|
|Fuel Type||Gas Carbureted|
|Fuel Capacity||8-gallon (30.3-L) single fuel tank with single fill location.|
|Fuel Indicator||Yes - electronic Sender|
|Drive Description||Two Exmark exclusive Parker unitized pump and wheel motor systems with no hoses, integrated cooling fans, shock valve, 1.7-quart integrated reservoir, spin-on filter and heavy-duty components. 12 cc pumps and 14. 5 cubic inch motors.|
|Speed||Infinitely variable speed selection from 0-10.0 mph (16 kmph) forward, 0-6.0 mph (9.7 kmph) reverse.|
|Deck Lift||Standard; foot-controlled deck lift changes cutting height and lifts the deck to maneuver around obstacles, or place in transport position.|
|Safety Package||Operator Presence Controls (OPC) and drive system interlock, with safety interlock system indicators.|
|ROPS||2-post foldable ROPS standard with seat belt and latch.|
|PTO Engagement||MagStop Electromagnetic 175 ft-lb clutch with spot brake|
|Drive Wheel Release||Allows unit movement without engine running.|
|Casters||.50" thick caster yoke arms.|
|Width / Cutting Deck||52"|
|Deck Style||Floating Deck|
|Deck Style Description||Full-floating UltraCut Series 4. Side discharge standard, with molded discharge chute and option to bag or mulch.|
|Deck Construction||10-gauge top that is formed and continuously seam welded, 7-gauge side skirt and 7-gauge formed and welded spindle mounting locations for improved strength and reduced weight.|
|Blade Tip Speed||Approximately 18,500 fpm.|
|Cutting Heights||1.0" (2.5 cm) to 5.5" (11.8 cm) in 0.25" (0.64 cm) increments adjustable from operator's seat.|
|Blades||3 Blades at 18.0" Length|
|Width||64.8 in. (164.6 cm)|
|Length||70 in. (177.8 cm)|
|Height||70 in. (177.8 cm)|
