Superior Air Filtration
This series comes standard with heavy-duty canister air filtration systems for longer engine life, more efficient performance and simple maintenance.
Rear Discharge Deck (60”)
Allows for increased productivity while mowing around trees, buildings and landscape, as well as more controlled discharge clippings to help keep the operator clean.
Commercial-grade, cast aluminum spindles feature sealed bearings to resist damage from moisture and impact, with no annual greasing required.
The S-Series can reach speeds up to 9mph* covering up to 5.5 acres per hour. *Based on the PNS740GKC60400 model.
The Pioneer features a bolstered seat with coil-spring suspension. Because operator comfort and productivity go hand-in-hand.
|Blade Spindles||No maintenance, sealed and non-greasable spindles; 7.75"-diameter cutter housing with 25mm(.98")diameter spindle shaft and splined blade driver.|
|Drive Tires||23 x 10.5-12 Super Turf®|
|Tractor Frame||Unibody, welded, heavy-duty 2" square tublar steel.|
|Steering Control||Hydraulically dampened twin levers, adjustable both fore and aft. Levers are also adjustable to 3 height positions.|
|Front Caster Tires||13 x 6.50-6, smooth tread, pneumatic.|
|Parking Brake||Lever-actuated pawl brake.|
|Seat||Deluxe, two-tone, bolstered suspension seat with Elastomeric Vibration Control material. Hinged mounting. Adjustment: Fore and aft from Operators' Position.|
|Electrical||12-volt battery with 15-amp alternator.|
|Engine Speed||3,700 rpm|
|Air Filter||Cyclonic Air Cleaner|
|Fuel Type||Gas Carbureted|
|Fuel Capacity||7-gallon (26.5.-L) single fuel tank.|
|Drive Description||Dual Hydro Gear ZT3400, hydrostatic transmission with charge pumps, relief valves and independent, replaceable filters.|
|Speed||Infinitely variable speed selection from 0-9.0 mph (14.5kmph) forward, 0-6.0 mph (9.7 kmph) reverse.|
|Deck Lift||Standard; foot-controlled deck lift changes cutting height and lifts the deck to maneuver around obstacles, or place in transport position.|
|Safety Package||Operator Presence Controls (OPC) and drive system interlock, with safety interlock system indicators.|
|ROPS||2-post foldable ROPS standard with seat belt and latch.|
|PTO Engagement||MagStop electromagnetic 200-ft-lb clutch|
|Drive Wheel Release||Allows unit movement without engine running.|
|Casters||.50" thick caster yoke arms|
|Width / Cutting Deck||60"|
|Deck Style||Floating Deck|
|Deck Style Description||Full-floating UltraCut Rear Discharge Deck. Rear-discharge standard with option to mulch.|
|Deck Construction||7-gauge high strength alloy top that is formed and continuously seam welded, with 7-gauge high strength alloy side skirt.|
|Blade Tip Speed||Approximately 18,500 fpm.|
|Cutting Heights||1.5" (3.8 cm) to 5.0" (12.7 cm) in 0.25" (0.6 cm) increments adjustable from operator position via foot-operated, deck-lift system.|
|Blades||3 Blades at 20.50" Length|
|Width||66.2 in. (168.1 cm)|
|Length||80.8 in (205.2 cm)|
|Height||72 in. (183 cm)|
