Reduces fuel consumption, fewer emissions and carbon footprint.
Delivers up to 25% in fuel savings.
Reduce Green House Gases
Fuel saved directly correlates to reduced harmful exhaust emissions, including green house gases.
Easy to Start
Easy start in any altitude or climate condition (no manual choke).
Closed loop (with O2 sensor) monitors combustion and keeps engine running at optimum levels.
Sequential Fuel Injection
Delivers the precise amount of fuel and spark where needed to maximize efficiency and power.
|Blade Spindles||Heavy Duty cast iron right-angle gearboxes.|
|Drive Tires||18 x 10.5-10 Multi-Trac® C/S.|
|Tractor Frame||Channeled and fully welded 1.5" x 1.5" x 0.187" wall tubing with a ground clearance of 4.0", str|
|Steering Control||FeatherTouch hand-control drive levers, low-force constant speed lever.|
|Front Caster Tires||8 x 3.0-4 semi-pneumatic.|
|Parking Brake||Wet disc, internal in wheel motor.|
|Seat||High-back, "EVC" (Elastomeric Vibration Control) seat, which has no springs to break.|
|Electrical||12-volt battery with 20-amp alternator.|
|Engine Series||Command™ EFI|
|Engine Type||Electronic Fuel Injected|
|Engine Speed||3,600 rpm|
|Air Filter||Heavy-duty canister air filtration|
|Fuel Type||Gas EFI|
|Fuel Capacity||7.5-gallon (28.4-L), pivoting tank for easier engine service.|
|Fuel Indicator||Translucent Visual|
|Drive Description||New Dual Hydro-Gear 12 cc variable displacement pumps power Hydro-Gear H Series motors.|
|Speed||Infinitely variable speed selection from 0-7.0 mph (11.3 kmph) forward, 0-4.5 mph (7.2 kmph) reverse.|
|Safety Package||Operator Presence Controls (OPC) and drive system interlock.|
|ROPS||Optional 2-post foldable ROPS with seat belt and latch.|
|PTO Engagement||Lever-actuated clutching belt with 6" brake band.|
|Drive Wheel Release||Allows movement without engine running.|
|Casters||0.50" thick rear caster fork|
|Width / Cutting Deck||48"|
|Deck Style||Floating Deck|
|Deck Style Description||Full Floating rear discharge cutting deck w/heavy duty gear driven spindle assembly. Patented Fill Reduction baffles standard.|
|Deck Construction||7-gauge sides joined by a continuous bead weld to a 10-gauge top, 3/16" wear guard is welded to the entire base of the deck, 7-gauge deck spindle supports, 0.25"-thick strap steel deck supports.|
|Blade Tip Speed||Approximately 18,500 fpm.|
|Cutting Heights||1.0" (2.54 cm) to 4.0" (10.2 cm) in 0.25" (0.64 cm) increments .|
|Blades||2 Blades at 25" Length|
|Bag Capacity||9.5 bushel (76 gallons)|
|Width||49.2 in. (125.0 cm)|
|Length||94.5 in. (240.0 cm)|
|Height||51.2 in. (130.0 cm)|
