Features
ZERO EFFORT ZERO TURNS
Patented SynchroSteer technology, pioneered by Cub Cadet, is a system of dual hydrostatic transmissions synchronized with steering-wheel control of all four wheels to create true zero-turn maneuverability. Not to mention, tremendous ease-of-use and stability.
ADVANCED MANEUVERABILITY, CONFIDENCE AND VERSATILITY
With the ease of steering-wheel control and stability of four-wheel steering, you'll have unprecedented command over hills and uneven terrain. And with the added benefits of select attachment support, you get the power to tack tasks year-round.
THE CUB CADET SIGNATURE CUT™
An advanced cutting system design with optimal airflow, blade overlap and floating deck deliver flawless cutting and bagging performance, low maintenance and durability year after year. And the addition of anti-scalping wheels and rear striping rollers (on select models) provide a professional-quality finish to make you the envy of the neighborhood.
Specifications
| ENGINE |
| Engine Type: 25 HP professional-grade Kohler 7000 Series V-Twin OHV |
| Cylinders/Material: 2/Cast-iron sleeve |
| Lubrication: Fully pressurized automotive-style oil pump w/ spin-on oil filter |
| MOWER DECK |
| Cutting Width/Blades: 60" triple-blade (high-lift) |
| Deck Lift: Hand lever adjustment w/ spring-assist |
| Deck Wash: Patented SmartJet™ high-pressure deck washing system |
| Deck Attach/Removal: QuickAttach™ in seconds (no tools required) |
| Deck Cutting Height: 1" - 4" (in .25" increments) |
| Anti-Scalping: 2 greasable heavy-duty gauge wheels, 1-nose premium gauge wheel |
| Deck Style/Construction: 11-gauge, floating, fabricated w/ 7-gauge reinforced plate |
| OPERATION |
| Safety Systems: Operator presence, RevTEK™ reverse mowing technology |
| Engine Start: Electric |
| PTO Clutch: Electronic fingertip engagement |
| Seat: 18" high-back seat w/ armrests |
| ELECTRICAL SYSTEM |
| Alternator: 12V - 15 amp regulated |
| Battery Voltage: 230 cold crank amp |
| GENERAL |
| Hour Meter: Standard electronic |
| ADDITIONAL SPECIFICATIONS |
| Fuel Tank Capacity: Single 2.8-gallon tank |
| Wheelbase: 43" |
| Overall Length: 70" |
| Engine Oil Capacity: 2 qt. |
| Reverse Speed: 3 mph |
| Forward Speed: 7 mph |
| Approximate Weight: 795 lbs. |
| POWER SYSTEM |
| Cruise Control: Standard/Foot operated |
| FRAME |
| Frame: Heavy-duty 12-gauge reinforced fully welded 1-piece full-length steel frame |
| COMFORT & CONTROL |
| Steering: Steering wheel control w/ quick-adjust tilt column |
| SPECIFICATIONS |
| Cup Holder: Standard |
| Turning Radius: Zero |
| STEERING |
| Front Axle: Fabricated, greasable |
| WARRANTY |
| Warranty: 3-year / 180 hours |
| ENGINE & DRIVE SYSTEM |
| Transmission: Dual Hydro-Gear® ZT-2800™ w/ oil reservoir and filter |
| WHEELS & SUSPENSION |
| Parking Brake: Foot pedal w/ mechanical locking |
