Features
AMAZING COMFORT
Comfortable high-back seat with standard armrests, over-sized adjustable lap bars with full-length comfort grips, roomy foot rest and easy-lift deck height adjuster - all designed for maximum comfort.
INCREDIBLE STRENGTH
Cub Cadet-certified engines, fully welded full-length steel frame, and tough fabricated decks with heavy-duty spindles deliver outstanding results year after year.
UNBEATABLE DURABILITY
The Cub Cadet Triple Guard Corrosion Defense System™ with E-Coat delivers automotive-grade corrosion resistance against the elements and wear and tear.
Specifications
| SPECIFICATIONS |
| Turning Radius: Zero |
| Cup Holder: Standard |
| STEERING |
| Front Axle: Fabricated, greasable |
| ENGINE |
| Cylinders/Material: 2/Cast-iron sleeve |
| Engine Type: 24 HP professional-grade Kawasaki® FR Series V-Twin OHV |
| Lubrication: Fully pressurized automotive-style oil pump w/ spin-on oil filter |
| ELECTRICAL SYSTEM |
| Battery Voltage: 230 cold crank amp |
| Alternator: 12V - 15 amp regulated |
| OPERATION |
| Safety Systems: Operator presence, RevTEK™ reverse mowing technology |
| Engine Start: Electric |
| PTO Clutch: Electronic fingertip engagement |
| Seat: High-back elasticity vibration control (EVC) suspension seat w/armrests |
| MOWER DECK |
| Cutting Width/Blades: 60" triple-blade (high-lift) |
| Deck Cutting Height: 1" - 5" |
| Deck Lift: Hand lever adjustment w/ spring assist |
| Anti-Scalping: 2 greasable heavy-duty gauge wheels |
| Deck Wash: Patented SmartJet™ high-pressure deck washing system |
| Deck Style/Construction: 11-gauge, floating, fabricated w/7-gauge reinforced plate |
| Deck Attach/Removal: QuickAttach™ in seconds (no tools required) |
| GENERAL |
| Hour Meter: Standard electronic |
| ADDITIONAL SPECIFICATIONS |
| Wheelbase: 43" |
| Overall Length: 70" |
| Reverse Speed: 4 mph |
| Fuel Tank Capacity: Twin 2.8 gal (5.6 gal. total) |
| Forward Speed: 8 mph |
| Engine Oil Capacity: 2.1 qt. |
| Approximate Weight: 730 lbs. |
| WARRANTY |
| Warranty: 4-year/500-hr limited warranty |
| FRAME |
| Frame: Heavy-duty 12-gauge reinforced fully-welded 1-piece full-length steel frame |
| Engine & Drive System |
| Transmission: Hydro-Gear™ ZT3100™ w/oil reservoir and filter |
| WHEELS & SUSPENSION |
| Parking Brake: Integrated parking brake in lap bars |
