Features
- Ideal for mowing slight rolling hills and several obstacles up to 5 acres
- Open frame design and hinged/removable floor pan allow easy access to the deck and engine for quick and simple maintenance
- A heavy-duty 11-gauge 60-in. fabricated triple-blade (high lift) deck
Specifications
| Engine & Drive System |
| Transmission: Dual Hydro-Gear™ ZT-2800™ w/oil reservoir and filter quickly leaves your lawn with a professional-quality finish |
| Engine Type: Kawasaki FR Series V-twin OHV |
| Horsepower / CC's: 24 HP - 726cc |
| Ground Speed: 7.5 mph Fwd / 3.5mph Rev zero-turn controlled ground speeds quickly leave your lawn with a professional-quality finish. |
| Fuel Capacity: 3.5 Gallon fuel tank capacity to keep you mowing and minimize time loss for refueling needs |
| MOWER DECK |
| Deck Height Adjustment: Foot pedal with spring assist creates the perfect cut 15 Positions |
| Cutting Height: 1'' - 4.5'' leads to a precise event cut |
| Spindle Construction: Sealed cast aluminum housing (maintenance-free) |
| Deck Blades: Triple Blade deck blades meaning fewer clumps and stragglers, finer clippings and increased evenness. |
| Deck Size/Type: 60'' Fabricated Aeroforce |
| Deck Material: A heavy-duty 11-gauge fabricated deck with reinforced leading edges, 1'' x 3/18'' trim side and an AeroForce™ cutting system has been independently tested and proven to deliver a best-in-class cut. Protected by the Cub Cadet Triple Guard Corrosion Defense System™ with E-Coat. |
| Deck Wash: SmartJet deck wash system provides high pressure water that cleans out grass and debris build-up under the deck |
| Leading Edge Reinforcement: Reinforced 1” x.375” welded steel bar stock |
| OPERATION |
| Seat Type: Automotive-inspired, ergonomic, fully adjustable premium 18'' high-back seat and a durable, advanced polymer seat suspension system optimizes comfort while reducing operators fatigue |
| Lap Bar / Steering Wheel Control: 3- way adjustable ergonomic lap bar design with integrated parking brake, and Mow-in-Reverse. Provides comfort with a simple operation |
| Park Brake / Braking: Intergrated system in Lap Bars for ease of use |
| Rear Tires: 20”x12”-10" Turf Master premium rear tires offer excellent traction, minimize turfing and provide a better ride on uneven ground at higher speeds |
| Front Tires: 13"x 6.5"-6" smooth tread front wheels pivot 180 degrees without turf damage |
| PTO Engagement: Electronic fingertip blade engagement PTO allows for smooth operation of the deck or attachments |
| Cruise Control: N/A |
| Headlight: Illuminating Dual-LED Headlights provide ultimate vision for mowing in low light conditions |
| CHASSIS |
| Frame: High-strength, continuous square 2'' x 2'' tubular steel frame with fully E-Coat lower frame and Triple Guard Corrosion Defense System™ protects against wear and tear. |
| Front Axle / Yokes: Fixed 2" x 2.5" fully welded tubular steel axle (e-coated) / 5/16" steel yokes provide premium strength |
| Rear Bumper: 2" x 2" Tubular steel bumper |
| ROPS: N/A |
| Rear Hitch: Standard |
| DIMENSIONS |
| Dimensions L/W/H: 80'' x 71'' x 48'' |
| Weight (approx): 640 lbs. |
