Features

  • Ideal for mowing slight rolling hills and several obstacles up to 5 acres
  • Open frame design and hinged/removable floor pan allow easy access to the deck and engine for quick and simple maintenance
  • A heavy-duty 11-gauge 50-in. fabricated triple-blade (high lift) deck

Specifications

Engine & Drive System
Transmission:  Dual Hydro-Gear™ ZT-2800™ w/oil reservoir and filter
quickly leaves your lawn with a professional-quality finish
Engine Type:  Kawasaki FR Series V-twin OHV
Horsepower / CC's - 23 HP - 726cc
Ground Speed - 7.5 mph Fwd / 3.5mph Rev zero-turn controlled ground speeds quickly leave your lawn with a professional-quality finish.
Fuel Capacity:  3.5 Gallon fuel tank capacity to keep you mowing and minimize time loss for refueling needs

MOWER DECK
Deck Height Adjustment:  Foot pedal with spring assist creates the perfect cut
15 Positions
Cutting Height:  1'' - 4.5'' leads to a precise event cut
Spindle Construction:  Sealed cast aluminum housing (maintenance-free)
Deck Blades:  Triple Blade deck blades
meaning fewer clumps and stragglers, finer clippings and increased evenness.
Deck Size/Type:  50'' Fabricated Aeroforce
Deck Material:  A heavy-duty 11-gauge fabricated deck with reinforced leading edges, 1'' x 3/18'' trim side and an AeroForce™ cutting system has been independently tested and proven to deliver a best-in-class cut. Protected by the Cub Cadet Triple Guard Corrosion Defense System™ with E-Coat.
Deck Wash:  SmartJet deck wash system provides high pressure water that cleans out grass and debris build-up under the deck
Leading Edge Reinforcement:  Reinforced 1” x.375” welded steel bar stock

OPERATION
Seat Type:  Automotive-inspired, ergonomic, fully adjustable premium 18'' high-back seat and a durable, advanced polymer seat suspension system optimizes comfort while reducing operators fatigue
Lap Bar / Steering Wheel Control:  3- way adjustable ergonomic lap bar design with integrated parking brake, and Mow-in-Reverse. Provides comfort with a simple operation
Park Brake / Braking:  Intergrated system in Lap Bars for ease of use
Rear Tires:  20”x12”-10" Turf Master premium rear tires offer excellent traction, minimize turfing and provide a better ride on uneven ground at higher speeds
Front Tires:  13"x 6.5"-6" smooth tread front wheels pivot 180 degrees without turf damage
PTO Engagement: Electronic fingertip blade engagement PTO allows for smooth operation of the deck or attachments
Cruise Control:  N/A
Headlight:   Illuminating Dual-LED Headlights provide ultimate vision for mowing in low light conditions

CHASSIS
Frame:  High-strength, continuous square 2'' x 2'' tubular steel frame with fully E-Coat lower frame and Triple Guard Corrosion Defense System™ protects against wear and tear.
Front Axle / Yokes:   Fixed 2" x 2.5" fully welded tubular steel axle (e-coated) / 5/16" steel yokes provide premium strength
Rear Bumper:  2" x 2" Tubular steel bumper
ROPS:  N/A
Rear Hitch: Standard

DIMENSIONS
Dimensions L/W/H:  80'' x 61'' x 48''
Weight (approx):  600 lbs.
