Features
STANDARD FEATURES. FULLY LOADED.
Conquer your challenge right off the lot with a roof, sealed windshield, winch, LED headlights and high-sided doors. All loaded standard on every 550 and 750.
CONVENIENT
With underhood storage, interior door handles and familiar automotive-style controls, you and your gear can stay organized and get to your challenge easily.
CAPABLE
Adjustable shocks and off-road tires with selectable locking front and rear differentials means your challenges from the field to the trail are no challenge at all.
COMFORTABLE
High-sided sealed doors and windshield offer protection from dirt, mud and water, while eliminating the need for additional hip and shoulder restraints. Plus, bolstered seats provide all-day comfort.
Specifications
| Specifications |
| Suspension Front/Rear: Independent Dual A-Arm |
| Mirrors: Standard Side View |
| Platform: Utility Vehicle |
| Total Payload: 1,100 lbs. |
| Doors: High-sided doors with interior and exterior handles, internal steel components |
| Cooling System: Liquid |
| Speed: up to 45 mph |
| Differential: selectable locking front/rear |
| Fuel Tank Capacity: 7.6 GAL. |
| Rear Brakes: Hydraulic disc |
| Air Cleaner: Dual-element |
| Series: CHALLENGER |
| Front Differential: Selectable Locking |
| WheelBase: 76.8" |
| Wheels: Aluminum |
| Engine Type: OHV / 1-Cylinder, 5 Valves |
| Fuel System: Electronic Fuel Injection (EFI) |
| Number of Passengers: 2 |
| Travel: 9" Front, 8.2" Rear |
| Roof: Standard |
| Cargo Bed: Glass-filled polypropylene |
| Winch: Included, 3,500 lbs. |
| Cargo Bed Payload: 500 lbs. |
| Available Colors: BLACK |
| Parking Brake: Mechanical (hand lever) |
| Front Tires: 26" x 9-14" |
| Front Brake: Hydraulic disc |
| Rear Differential: Selectable Locking |
| Frame: Steel tubing, reinforced with high-strength low alloy (HSLA) steel |
| Hitch Receiver: 2" - Class 1 |
| Bumper: Steel tube |
| Power Port: 12V in-dash |
| Headlights: LED (light-emiting diode), daytime running lights LED daytime running lights (high/low beam) |
| Cargo Bed Length/Width/Height: 34" x 46" x 11" |
| Dry Weight: 1,580 lb. |
| Engine HP: 37.5 HP |
| Seating: Bench with center cupholders |
| Engine Displacement: 735cc |
| Storage: Glove box, Dash bin, Underhood |
| Steering: Factory-installed Electronic Power Steering (EPS), tilting steering wheel |
| Transmission: Enclosed CVT |
| Minimum Ground Clearance: 12 in. |
| Towing Capacity: 1,200 lbs. |
| Windshield: Standard- Sealed one-piece, quick attach |
