Features

UPGRADED POWER AND RELIABILITY

Only the XT3 has an automotive-style direct shaft drive. That means no belts to the drive system to slip or break - just maximum power delivery and durability even when cutting through tall grass or using attachments. Matched with a cast-iron transmission and front axle, the XT3 provides reliable Cub Cadet performance.

DELUXE FEATURES

Rugged,low maintenance LED headlights, adjustable high-back seat with armrests, automatic transmission and cruise control - all standard.

STRONGER OPTIONS

Extra-tough stamped and fabricated cutting decks plus an advanced cutting system built with rugged components ensure unbeatable durability, breakthrough bagging performance, and of course, the beautiful Cub Cadet Signature Cut. Decks sold separately.

Specifications

STEERING
Rear Axle: 25mm w/ dual PM steel drive hubs
Steering/Turning Radius: Sector and pinion/18"
Front Pivot Bar: Heavy-duty cast-iron (5-year limited warranty/unlimited hours) with dual grease fittings
Front Axles: Heavy-duty 3/4" through machined bushings
Ball Joints: Fully-adjustable/Automotive-style

ENGINE
Engine Type: 22.5 HP professional-grade Kohler® Command OHV
Cylinders/Material: Twin/Cast-iron sleeve
Lubrication: Fully pressurized automotive-style oil pump w/ spin-on oil filter

CONTROLS
Brakes: Automotive-style disc

CHASSIS
Hood: Front pivot, high impact

MOWER DECK
Cutting Width/Blades: 42", 50", 54" Stamped (SOLD SEPARATELY)
Deck Cutting Height: 1.5" - 4"
Anti-scalping Wheels (front/rear): N/A
Mulch Kit: Optional
Deck Spindles: Cast aluminum spindle housings and precision tapered roller bearings
Deck Pulleys: All steel with heavy-duty bearings
Deck Attach/Removal: QuickAttach™ (no tools required)
Deck Wash: Patented SmartJet™ high-pressure deck washing system

OPERATION
PTO Clutch: Electronic fingertip engagement
Deck Lift: Lever/10-position/spring-assisted
Seat: Deluxe high-back seat with armrests and 6" slide
Arm Rests: Standard
Warranty: 4-year unlimited hours (includes powertrain) & 5-year chassis & front axle unlimited hours/limited lifetime fabricated deck shell

ELECTRICAL SYSTEM
Battery: 300 cold crank amps
Charging System: Flywheel alternator - 15 amp regulated
Headlights: LED
System Monitor Package: Digitial hour meter/service minder, oil, battery, brake and PTO start sequence

GENERAL
Safety Systems: Neutral Start, operator presence, reverse safety switch, brake pedal lock, RevTek reverse mowing technology

ADDITIONAL SPECIFICATIONS
Tires (Front/Rear): 16" x 6.5" ball bearings/23" x 10.5"
Tire Tread: Turf Master
Forward Speed: 6.5 mph
Reverse Speed: 3.5 mph
Fuel Tank Capacity: 3.3 gal. easy fill, rustproof
Engine Oil Capacity: 1.9 qt.
Wheelbase: 50.6"
Estimated Weight: 800 lbs.

POWER SYSTEM
Powertrain: Direct Shaft Drive, foot-controlled hydrostatic Hydro-Gear™ cast-iron transmission
Rear Differential Lock: N/A
Engine to Transmission: Heavy-duty shaft drive
Cruise Control: Soft touch engagement
Transmission Housing: Cast iron

FRAME
Frame: Fully robotically-welded twin C-channel frame assembly (5-year limited warranty)
Bumper: Heavy-duty steel
