Features
NEW V-TWIN EFI ENGINE
The new Cub Cadet 679cc twin EFI engine available on the XT2 LX46 and SLX50 packs high-performance power. Not to mention reduced maintenance and up to 25% less fuel consumption.
INCREASED CONVENIENCE
Convenient features like keyless engine and Cub Connect™ Bluetooth® Maintenance Monitoring are available on select XT2 models.
DIFF-LOCK
Foot-controlled traction control differential lock for all weather conditions and cutting terrains available on select XT2 tractors. Built to last with Tuff-Torq K62 Hydrostatic transmission featuring steel gears.
Specifications
Engine |
Engine Type: 22 HP professional-grade Kohler® 7000 Series V-Twin OHV |
Cylinders/Material: Twin/Cast-iron sleeve |
Lubrication: Fully pressurized automotive-style oil pump w/ spin-on oil filter |
CHASSIS |
Hood: Front pivot, High impact with quick removal design |
MOWER DECK |
Deck Spindles: 3/4" with steel cap and Triple Lip Sealed |
Deck Cutting Height: 1" - 4" |
Deck Pulleys: Split steel spindle pulleys/oversized heavy-duty idlers |
Mulch Kit: Optional |
Deck Attach/Removal: QuickAttach™ (no tools required) |
Anti-scalping Wheels (front/rear): 2 Ball/2 Narrow |
Deck Wash: Patented SmartJet™ high-pressure deck washing system |
Cutting Width/Blades: 42"/Twin Blades |
Deck Construction: Stamped |
ELECTRICAL SYSTEM |
Battery:300 cold crank amps |
Charging System: Flywheel alternator - 15 amp regulated |
Headlights: NEW LED High Illumination |
System Monitor Package: Digitial hour meter/service minder, oil, battery, brake and PTO start sequence |
Cub Connect™: N/A |
OPERATION |
PTO Clutch: Smooth lever engagement |
Deck Lift: Lever/12-position/spring-assisted |
Seat: NEW Cub Comfort™ high-back seat with 10 degree incline and slide |
GENERAL |
Safety Systems: Neutral Start, operator presence, reverse safety switch, brake pedal lock, RevTek reverse mowing technology |
ADDITIONAL SPECIFICATIONS |
Tires (Front/Rear): 15" x 6" ball bearing/20" x 8" |
Tire Tread: Multi Trac |
Forward Speed: 5.5 mph |
Reverse Speed: 3.1 mph |
Fuel Tank Capacity: 3 gal. easy fill, rustproof |
Engine Oil Capacity: 2 qt. |
Wheelbase: 47" |
Estimated Weight: 580 lbs. |
POWER SYSTEM |
Powertrain: Tuff Torq® foot-controlled hydrostatic transmission (K46) |
Rear Differential Lock: N/A |
Engine to Transmission: Heavy-duty belt |
Cruise Control: Soft touch engagement |
Transmission Housing: Cast aluminum |
FRAME |
Frame: Fully robotically-welded frame with new e-coating corrosion defense system (5-year limited warranty) |
Bumper: Single-tube |
DIMENSIONS |
Length/Width/Height: 68"/50"/42.5" |
SPECIFICATIONS |
Arm Rests: Standard |
Warranty: 3-year unlimited hours (includes powertrain) & 5-year chassis & front axle unlimited hours/limited lifetime fabricated deck shell |
STEERING |
Rear Axle: 3/4" w/dual PM steel drive hubs |
Steering/Turning Radius: NEW optimized steering system, manual sector and pinion/16" |
Front Pivot Bar: Heavy-duty cast-iron (5-year limited warranty/unlimited hours) |
Front Axles: Heavy-duty 3/4" through machined bushings |
Ball Joints: Fully-adjustable/Automotive-style |
CONTROLS |
Brakes: Automotive-style disc |
