Features
NEW V-TWIN EFI ENGINE
The new Cub Cadet 679cc twin EFI engine available on the XT2 LX46 and SLX50 packs high-performance power. Not to mention reduced maintenance and up to 25% less fuel consumption.
INCREASED CONVENIENCE
Convenient features like keyless engine and Cub Connect™ Bluetooth® Maintenance Monitoring are available on select XT2 models.
DIFF-LOCK
Foot-controlled traction control differential lock for all weather conditions and cutting terrains available on select XT2 tractors. Built to last with Tuff-Torq K62 Hydrostatic transmission featuring steel gears.
Specifications
| Engine |
| Engine Type: 22 HP professional-grade Kohler® 7000 Series V-Twin OHV |
| Cylinders/Material: Twin/Cast-iron sleeve |
| Lubrication: Fully pressurized automotive-style oil pump w/ spin-on oil filter |
| CHASSIS |
| Hood: Front pivot, High impact with quick removal design |
| MOWER DECK |
| Deck Spindles: 3/4" with steel cap and Triple Lip Sealed |
| Deck Cutting Height: 1" - 4" |
| Deck Pulleys: Split steel spindle pulleys/oversized heavy-duty idlers |
| Mulch Kit: Optional |
| Deck Attach/Removal: QuickAttach™ (no tools required) |
| Anti-scalping Wheels (front/rear): 2 Ball/2 Narrow |
| Deck Wash: Patented SmartJet™ high-pressure deck washing system |
| Cutting Width/Blades: 42"/Twin Blades |
| Deck Construction: Stamped |
| ELECTRICAL SYSTEM |
| Battery:300 cold crank amps |
| Charging System: Flywheel alternator - 15 amp regulated |
| Headlights: NEW LED High Illumination |
| System Monitor Package: Digitial hour meter/service minder, oil, battery, brake and PTO start sequence |
| Cub Connect™: N/A |
| OPERATION |
| PTO Clutch: Smooth lever engagement |
| Deck Lift: Lever/12-position/spring-assisted |
| Seat: NEW Cub Comfort™ high-back seat with 10 degree incline and slide |
| GENERAL |
| Safety Systems: Neutral Start, operator presence, reverse safety switch, brake pedal lock, RevTek reverse mowing technology |
| ADDITIONAL SPECIFICATIONS |
| Tires (Front/Rear): 15" x 6" ball bearing/20" x 8" |
| Tire Tread: Multi Trac |
| Forward Speed: 5.5 mph |
| Reverse Speed: 3.1 mph |
| Fuel Tank Capacity: 3 gal. easy fill, rustproof |
| Engine Oil Capacity: 2 qt. |
| Wheelbase: 47" |
| Estimated Weight: 580 lbs. |
| POWER SYSTEM |
| Powertrain: Tuff Torq® foot-controlled hydrostatic transmission (K46) |
| Rear Differential Lock: N/A |
| Engine to Transmission: Heavy-duty belt |
| Cruise Control: Soft touch engagement |
| Transmission Housing: Cast aluminum |
| FRAME |
| Frame: Fully robotically-welded frame with new e-coating corrosion defense system (5-year limited warranty) |
| Bumper: Single-tube |
| DIMENSIONS |
| Length/Width/Height: 68"/50"/42.5" |
| SPECIFICATIONS |
| Arm Rests: Standard |
| Warranty: 3-year unlimited hours (includes powertrain) & 5-year chassis & front axle unlimited hours/limited lifetime fabricated deck shell |
| STEERING |
| Rear Axle: 3/4" w/dual PM steel drive hubs |
| Steering/Turning Radius: NEW optimized steering system, manual sector and pinion/16" |
| Front Pivot Bar: Heavy-duty cast-iron (5-year limited warranty/unlimited hours) |
| Front Axles: Heavy-duty 3/4" through machined bushings |
| Ball Joints: Fully-adjustable/Automotive-style |
| CONTROLS |
| Brakes: Automotive-style disc |
