Features
Advanced Cutting Performance
A new muscular cutting system features stamped and fabricated cutting deck options built with heavy duty materials and an advanced belt design, ensuring durability and reliability while delivering the pristine Cub Cadet Signature Cut™ and an unprecedented level of bagging performance.
Exceptional Corrosion Protection
Only Cub Cadet offers the protection of the Corrosion Defense System with E-Coat. A multi-step process electronically applies automotive-grade corrosion resistance with meticulous care to protect against wear and tear.
Incredibly Responsive Handling
The XT 1’s new steering system delivers optimized command and control at every turn.
Specifications
| ENGINE |
| Engine Type: 547cc EFI Cub Cadet Single Cylinder Engine. |
| Cylinders/Material: Single/Cast-iron sleeve |
| Lubrication: Fully pressurized automotive-style oil pump w/ spin-on oil filter |
| CHASSIS |
| Hood: Front pivot, High impact with quick removal design |
| ELECTRICAL SYSTEM |
| Battery: 230 cold crank amps |
| Charging System: Flywheel Alternator - 12 amp regulated |
| Headlights: NEW LED High Illumination |
| System Monitor Package: Digitial hour meter/service minder, oil, battery, brake and PTO start sequence |
| Cub Connect™: N/A |
| OPERATION |
| PTO Clutch: Smooth lever engagement |
| Deck Lift: Lever/12-position/spring assisted |
| Seat: NEW Cub Comfort™ high-back seat with 10 degree incline and slide |
| MOWER DECK |
| Cutting Width/Blades: 42"/Twin Blades |
| Deck Construction: Stamped |
| Deck Cutting Height: 1" - 4" |
| Anti-scalping Wheels (front/rear): 2 Ball/2 Narrow |
| Mulch Kit: Optional |
| Deck Spindles: 3/4" with steel cap and Triple Lip Sealed |
| Deck Pulleys: Split steel spindle pulleys/oversized heavy-duty idlers |
| Deck Attach/Removal: QuickAttach™ (no tools required) |
| Deck Wash: Patented SmartJet™ high-pressure deck washing system |
| GENERAL |
| Safety Systems: Neutral Start, operator presence, reverse safety switch, brake pedal lock, RevTek reverse mowing technology |
| ADDITIONAL SPECIFICATIONS |
| Tires (Front/Rear): 15" x 6" sleeve bearing/20" x 8" |
| Tire Tread: Turf Saver |
| Forward Speed: 5.5 mph |
| Reverse Speed: 3.1 mph |
| Fuel Tank Capacity: 3 gal. easy fill, rustproof |
| Engine Oil Capacity: 1.8 qt. |
| Wheelbase: 47" |
| Estimated Weight: 410 lbs. |
| POWER SYSTEM |
| Powertrain:Tuff Torq® foot-controlled hydrostatic transmission (K46) |
| Rear Differential Lock: N/A |
| Engine to Transmission: Heavy-duty belt |
| Cruise Control: Soft touch engagement |
| Transmission Housing: Cast aluminum |
| FRAME |
| Frame: Fully robotically-welded frame with new e-coating corrosion defense system (5-year limited warranty) |
| Bumper: Optional |
| DIMENSIONS |
| Length/Width/Height: 68"/50"/42.5" |
| STEERING |
| Rear Axle: 3/4" w/dual PM steel drive hubs |
| Steering/Turning Radius: NEW optimized steering system, manual sector and pinion/16" |
| Front Pivot Bar: Heavy-duty cast-iron (5-year limited warranty/unlimited hours) |
| Front Axles: Heavy-duty 3/4" through machined bushings |
| Ball Joints: Fully-adjustable/Automotive-style |
| CONTROLS |
| Brakes: Automotive-style disc |
