Features
Advanced Cutting Performance
A new muscular cutting system features stamped and fabricated cutting deck options built with heavy duty materials and an advanced belt design, ensuring durability and reliability while delivering the pristine Cub Cadet Signature Cut™ and an unprecedented level of bagging performance.
Exceptional Corrosion Protection
Only Cub Cadet offers the protection of the Corrosion Defense System with E-Coat. A multi-step process electronically applies automotive-grade corrosion resistance with meticulous care to protect against wear and tear.
Incredibly Responsive Handling
The XT 1’s new steering system delivers optimized command and control at every turn.
Specifications
| ENGINE |
| Engine Type: 18 HP professional-grade Kohler® Courage OHV |
| Cylinders/Material: Single/Cast-iron sleeve |
| Lubrication: Fully pressurized automotive-style oil pump w/ spin-on oil filter |
| POWER SYSTEM |
| Powertrain: Tuff Torq® foot-controlled hydrostatic transmission (K46) |
| Rear Differential: N/A |
| Engine to Transmission: Heavy-duty belt |
| Cruise Control: Soft touch engagement |
| Transmission Housing: Cast aluminum |
| STEERING |
| Rear Axle: 3/4" w/dual PM steel drive hubs |
| Steering/Turning Radius: NEW optimized steering system, manual sector and pinion/16" |
| Front Pivot Bar: Heavy-duty cast-iron (5-year limited warranty/unlimited hours) |
| Front Axles: Heavy-duty 3/4" through machined bushings |
| Ball Joints: Fully-adjustable/Automotive-style |
| ELECTRICAL SYSTEM |
| Battery: 230 cold crank amps |
| Charging System: Flywheel Alternator - 12 amp regulated |
| Headlights: NEW LED High Illumination |
| System Monitor Package: Digitial hour meter/service minder, oil, battery, brake and PTO start sequence |
| Cub Connect™: N/A |
| Safety Systems: Neutral Start, operator presence, reverse safety switch, brake pedal lock, RevTek reverse mowing technology |
| OPERATION |
| PTO Clutch: Smooth lever engagement |
| Deck Lift: Lever/12-position/spring assisted |
| Brakes: Automotive-style disc |
| Seat: NEW Cub Comfort™ high-back seat with 10 degree incline and slide |
| MOWER DECK |
| Cutting Width/Blades: 42"/Twin Blades |
| Deck Construction: Stamped |
| Deck Cutting Height: 1" - 4" |
| Anti-scalping Wheels (front/rear): 2 Ball/2 Narrow |
| Mulch Kit: Optional |
| Deck Spindles: 3/4" with steel cap and Triple Lip Sealed |
| Deck Pulleys: Split steel spindle pulleys/oversized heavy-duty idlers |
| Deck Attach/Removal: QuickAttach™ (no tools required) |
| Deck Wash: Patented SmartJet™ high-pressure deck washing system |
| WARRANTY |
| Warranty : 3-year Unlimited Hours (includes Powertrain) & 5-year Chassis & Front Axle Unlimited Hours/limited lifetime fabricated deck shell |
