Features
Advanced Cutting Performance
A new muscular cutting system features stamped and fabricated cutting deck options built with heavy duty materials and an advanced belt design, ensuring durability and reliability while delivering the pristine Cub Cadet Signature Cut™ and an unprecedented level of bagging performance.
Exceptional Corrosion Protection
Only Cub Cadet offers the protection of the Corrosion Defense System with E-Coat. A multi-step process electronically applies automotive-grade corrosion resistance with meticulous care to protect against wear and tear.
Incredibly Responsive Handling
The XT 1’s new steering system delivers optimized command and control at every turn.
Specifications
| STEERING |
| Steering/Turning Radius |
| Optimized steering system, manual sector and pinion/16" |
| Front Pivot Bar |
| Heavy-duty cast-iron (5-year limited warranty/unlimited hours) |
| Front Axles |
| heavy-duty cast-iron |
| Ball Joints |
| Fully-adjustable/Automotive-style |
| ENGINE |
| Engine Type |
| 25 HP professional-grade Kohler® 7000 Series OHV |
| Cylinders/Material |
| Twin/Cast-iron sleeve |
| Lubrication |
| Fully pressurized automotive-style oil pump w/ spin-on oil filter |
| CONTROLS |
| Brakes |
| Automotive-style disc |
| CHASSIS |
| Hood |
| Front pivot, High impact with quick removal design |
| MOWER DECK |
| Deck Lift |
| Lever/12-position/spring assisted |
| Cutting Width/Blades |
| 54"/triple blade |
| Deck Construction |
| Fabricated |
| Deck Cutting Height |
| 1" - 4" |
| Anti-scalping Wheels (front/rear) |
| 2 Ball/2 Ball/Nose Roller |
| Mulch Kit |
| Optional |
| Deck Attach/Removal |
| QuickAttach™ (no tools required) |
| Deck Wash |
| Patented SmartJet™ high-pressure deck washing system |
| ELECTRICAL SYSTEM |
| Battery Voltage |
| 230 cold crank amps |
| Charging System |
| Flywheel Alternator - 12 amp regulated |
| Headlights |
| LED High Illumination |
| System Monitor Package |
| Digital hour meter, change oil service minder, battery voltage monitor, park brake and PTO start sequence LED's |
| Cub Connect™ |
| Bluetooth® equipped |
| OPERATION |
| Engine Start |
| Electric |
| Safety Systems |
| Neutral Start, operator presence, reverse safety switch, brake pedal lock, RevTek reverse mowing technology |
| PTO Clutch |
| Electronic fingertip engagement |
| Seat |
| Cub Comfort™ high-back seat with 10 degree incline and slide |
| ADDITIONAL SPECIFICATIONS |
| Tires (Front/Rear) |
| 16" x 6.5" sleeve bearing/22" x 9.5" |
| Tire Tread |
| Turf Saver |
| Forward Speed |
| 6.2 mph |
| Reverse Speed |
| 3.1 mph |
| Fuel Tank Capacity |
| 3 gal. easy fill, rustproof |
| Engine Oil Capacity |
| 2 qt. |
| Wheelbase |
| 47" |
| Estimated Weight |
| 530 lbs. |
| POWER SYSTEM |
| Powertrain |
| Tuff Torq® foot-controlled hydrostatic transmission (K62) |
| Engine to Transmission |
| Heavy-duty belt |
| Cruise Control |
| Soft touch engagement |
| Transmission Housing |
| Cast aluminum |
| WARRANTY |
| Warranty |
| 3-year unlimited hours (includes powertrain) & 5-year chassis & front axle unlimited hours/limited lifetime fabricated deck shell |
| DIMENSIONS |
| Length/Width/Height |
| 72.5"/60"/44.5" |
| FRAME |
| Frame |
| Fully robotically-welded frame with new e-coating corrosion defense system (5-year limited warranty) |
| Bumper |
| Single-tube |
