Features
MAXIMIZE YOUR WORKDAY
The steering wheel zero-turn option increases hillside stability, helping you cover acres up to 10% faster than comparable lap bar units. Plus, with the power of high-performance engines, you can tackle tough jobs and achieve a quality cut, day in and day out.
BEST-IN-CLASS DECK
Tackle the toughest conditions with the industry-leading only triple-7-gauge steel cutting deck: a 7-gauge deck shell with 7-gauge top and bottom reinforcements. Designed for durability, our decks produce a quality cut you can always count on.
MAINTENANCE MADE EASIER
Slash downtime thanks to Cub Cadet’s new spindle design. Completely sealed, dual double-row ball bearings make the spindle maintenance-free for its lifetime, and anti-friction washers prevent self-tightening, making blade maintenance easier.
PIVOTING FRONT AXLE
A pivoting front axle allows the front end of the PRO Z to ride across unseen terrain while protecting the quality of the cut. The frame and axle float as the PRO Z moves, allowing the deck to adapt to the shape of the terrain and avoid scalping and turf damage.
Specifications
| STEERING |
| Lap Bar / Steering Wheel Adjustment: Multi-position Quick-adjust steering column |
| CHASSIS |
| Rear Bumper: 5/16" Thick Steel rear engine guard/pre-drilled mounting points for attachments with integrated rear hitch |
| Front Axle / Yokes: 2" x 3" solid steel and 3/8" thick steel with sealed ball bearing front yokes |
| Frame: Fully welded, full-length 3/8 x 5" laser cut steel / integrated tie-down slots |
| ROPS: 2" x 2" quick-latch tool-less foldable 3 position |
| DIMENSIONS |
| Weight (approx): 1562 lbs. |
| L / W / H with discharge chute UP and ROPs DOWN: 86" L x 62" W x 52" H |
| OPERATION |
| Rear Tires: 23" x 10.5" - 12" (Turf Master) |
| Cruise Control: N/A |
| Lap Bar / Steering Wheel Control: High Performance Steering Wheel with Foot-pedal Control |
| Park Brake / Braking: Hand-operated lever with integrated hydro pump release lever |
| Throttle/PTO/Key Switch: HD Low-profile throttle lever, sealed key switch & electronic fingertip engagement pto |
| PTO Clutch: Warner PTO Clutch (200 ft. lb.) with Soft-Start |
| Seat Type: High-back dial suspension with EVC cushion, padded arm rests ISO mounted base (lateral suspension) angle back adjust and lumbar support seat belt |
| Front Tires: 16" x 6.5" - 8" turf |
| Safety Systems: Operator presence |
| MOWER DECK |
| Rolled Leading Edge Reinforcement: 1/4" (.250") steel |
| Top Reinforcement(s): 7ga. (.187") top plate |
| Bottom Reinforcement: 7ga. (.187") bottom plate |
| Deck Height Adjustment: Foot pedal with spring assist 16 Positions |
| Spindle Construction: 8" sealed cast aluminum housing (maintenance-free) |
| Side Construction: 5/16"(.313) steel on trim and discharge sides |
| Deck Size/Type: 60" FABRICATED DECK |
| Spindle Covers: Steel - Tooless Quick Release |
| Discharge Chute: High-density, impact-resistant rubber |
| Cutting Height: 1" - 5" |
| Deck Material: fabricated 7ga. (.187”) steel shell |
| Trim-Side Wear Guard: 3/4" Thick UHMW-PE Replaceable Trim-side Wear Guard |
| Blade-Tip Speed (Approx): 18,500 fpm |
| Deck Blades: Triple-blade / High-lift blade (standard) Marbain Blade |
| Anti-Scalping: 2 Front HD w/ Bushings & Grease Zerk |
| Deck Style/Construction: 7ga. top plate 7ga. bottom reinforcement ¼” rolled leading edge |
| GENERAL |
| Cup Holder: Intergrated into Side Pod |
| Hour Meter: Standard electronic |
| ENGINE & DRIVE SYSTEM |
| Ground Speed: Fwd: 12 mph / Rev: 6 mph |
| Horsepower / CC's: 31hp - 999cc |
| Engine Type: Kawasaki FX921v |
| Fuel Capacity: Twin 7.45 gal. tanks (14.9 gal. total) with electronic fuel gauge |
| Transmission: Parker HTG 14cc pump 280cc wheel motor |
