Cub Cadet PRO Z 154 S EFI

Double tap to zoom



Features

MAXIMIZE YOUR WORKDAY

The steering wheel zero-turn option increases hillside stability, helping you cover acres up to 10% faster than comparable lap bar units. Plus, with the power of high-performance engines, you can tackle tough jobs and achieve a quality cut, day in and day out.

BEST-IN-CLASS DECK

Tackle the toughest conditions with the industry-leading only triple-7-gauge steel cutting deck: a 7-gauge deck shell with 7-gauge top and bottom reinforcements. Designed for durability, our decks produce a quality cut you can always count on.

MAINTENANCE MADE EASIER

Slash downtime thanks to Cub Cadet’s new spindle design. Completely sealed, dual double-row ball bearings make the spindle maintenance-free for its lifetime, and anti-friction washers prevent self-tightening, making blade maintenance easier.

PIVOTING FRONT AXLE

A pivoting front axle allows the front end of the PRO Z to ride across unseen terrain while protecting the quality of the cut. The frame and axle float as the PRO Z moves, allowing the deck to adapt to the shape of the terrain and avoid scalping and turf damage.

Specifications

STEERING
Lap Bar / Steering Wheel Adjustment:  Multi-position Quick-adjust steering column

CHASSIS
Rear Bumper:  5/16" Thick Steel rear engine guard/pre-drilled mounting points for attachments with integrated rear hitch
ROPS:  2" x 2" quick-latch tool-less foldable 3 position
Frame:  Fully welded, full-legnth 12ga. channel frame with 14ga. reinforcements
Front Axle / Yokes:  2" x 3" solid steel and 3/8" thick steel with sealed ball bearing front yokes

OPERATION
PTO Clutch:  Warner Clutch - 125 ft lb.
Park Brake / Braking:  Foot-operated pedal
Front Tires:  13" x 6.5" - 6" (turf tread)
Seat Type:  High-back suspension with seat belt, adjustable arm rests and 6" seat travel
Lap Bar / Steering Wheel Control:  High Performance Steering Wheel with Foot-pedal Control
Throttle/PTO/Key Switch:  HD Low-profile throttle lever, sealed key switch & electronic fingertip engagement pto
Rear Tires:  23" x 10.5" - 12" (Turf Master)
Cruise Control:  Standard - Foot operated pedal engagement

DIMENSIONS
Weight (approx):   1000 lbs.
L / W / H with discharge chute UP and ROPs DOWN:  80" L x 56" W x 48" H

MOWER DECK
Deck Height Adjustment:  Hand Lever / 15 position / spring assist
Deck Size/Type:  54" Fabricated Deck
Top Reinforcement(s):  2ga. and 11 ga. top plate
Leading Edge Reinforcement:  1/4" (.250") steel
Bottom Reinforcement:  7ga. (.175") steel
Spindle Construction:  5" sealed cast aluminum housing (maintenance-free)
Deck Blades:  3 high-lift Marbain® blades / 18,500 fpm (approx.)
Side Construction:  5/16"(.313) steel on trim and discharge sides
Cutting Height:  1" - 5"
Trim-Side Wear Guard:  3/4" Thick UHMW-PE Replaceable Trim-side Wear Guard
Discharge Chute:  High-density, impact-resistant rubber
Deck Style/Construction:  Floating, fabricated 10ga. (.135”) steel shell (e-coated)
Anti-Scalping: 2 Front HD w/ Bushings & Grease Zerk

GENERAL
Cup Holder:  Intergrated into Side Pod
Hour Meter:  Standard electronic

ENGINE & DRIVE SYSTEM
Engine Type:  Kohler Confidant EFI Closed Loop EZT-750
Horsepower / CC's:  27hp - 747cc
Ground Speed:  9.5mph fwd. / 4.5mph rev.
Fuel Capacity:  Twin tanks - 3.5 gallon ea. (7 gallon total) with oversized filler opening
Transmission:  12cc Hydro-Gear® ZT 3400 with charge pumps
