Features
MAXIMIZE YOUR WORKDAY
The steering wheel zero-turn option increases hillside stability, helping you cover acres up to 10% faster than comparable lap bar units. Plus, with the power of high-performance engines, you can tackle tough jobs and achieve a quality cut, day in and day out.
BEST-IN-CLASS DECK
Tackle the toughest conditions with the industry-leading only triple-7-gauge steel cutting deck: a 7-gauge deck shell with 7-gauge top and bottom reinforcements. Designed for durability, our decks produce a quality cut you can always count on.
MAINTENANCE MADE EASIER
Slash downtime thanks to Cub Cadet’s new spindle design. Completely sealed, dual double-row ball bearings make the spindle maintenance-free for its lifetime, and anti-friction washers prevent self-tightening, making blade maintenance easier.
PIVOTING FRONT AXLE
A pivoting front axle allows the front end of the PRO Z to ride across unseen terrain while protecting the quality of the cut. The frame and axle float as the PRO Z moves, allowing the deck to adapt to the shape of the terrain and avoid scalping and turf damage.
Specifications
| STEERING |
| Lap Bar / Steering Wheel Adjustment: Multi-position Quick-adjust steering column |
| CHASSIS |
| ROPS: 2" x 2" quick-latch tool-less foldable 3 position |
| Frame: Fully welded, full-legnth 12ga. channel frame with 14ga. reinforcements |
| Front Axle / Yokes: 2" x 3" solid steel and 3/8" thick steel with sealed ball bearing front yokes |
| Rear Bumper: 5/16" Thick Steel rear engine guard/pre-drilled mounting points for attachments with integrated rear hitch |
| OPERATION |
| Throttle/PTO/Key Switch: High Performance Steering Wheel with Foot-pedal Control |
| PTO Clutch: Warner Clutch - 125 ft lb. |
| Seat Type: High-back suspension with seat belt, adjustable arm rests and 6" seat travel |
| Lap Bar / Steering Wheel Control: High Performance Steering Wheel with Foot-pedal Control |
| Rear Tires: 23" x 10.5" - 12" (Turf Master) |
| Front Tires: 13" x 6.5" - 6" (turf tread) |
| Cruise Control: Standard - Foot operated pedal engagement |
| Park Brake / Braking: Foot-operated pedal |
| DIMENSIONS |
| Weight (approx): 1000 lbs. |
| L / W / H with discharge chute UP and ROPs DOWN: 80" L x 49" W x 48" H |
| MOWER DECK |
| Trim-Side Wear Guard: 3/4" Thick UHMW-PE Replaceable Trim-side Wear Guard |
| Spindle Construction: 5" sealed cast aluminum housing (maintenance-free) |
| Deck Style/Construction: Floating, fabricated 10ga. (.135”) steel shell (e-coated) |
| Deck Blades: 3 high-lift Marbain® blades / 18,500 fpm (approx.) |
| Deck Size/Type: 48" Fabricated Deck |
| Deck Height Adjustment: Hand Lever / 15 position / spring assist |
| Discharge Chute: High-density, impact-resistant rubber |
| Top Reinforcement(s): 2ga. (.250") top plate |
| Side Construction: 5/16"(.313) steel on trim and discharge sides |
| Leading Edge Reinforcement: 1/4" (.250") steel |
| Cutting Height: 1" - 5" |
| Bottom Reinforcement: 7ga. (.175") steel |
| Anti-Scalping: 2 Front HD w/ Bushings & Grease Zerk |
| GENERAL |
| Cup Holder: Intergrated into Side Pod |
| Hour Meter: Standard electronic |
| ENGINE & DRIVE SYSTEM |
| Engine Type: Kohler Confidant EFI Closed Loop EZT-740 |
| Horsepower / CC's: 25hp - 747cc |
| Fuel Capacity: Twin tanks - 3.5 gallon ea. (7 gallon total) with oversized filler opening |
| Ground Speed: 9.5mph fwd. / 4.5mph rev. |
| Transmission: 12cc Hydro-Gear® ZT 3400 with charge pumps |
